Nissan Titan. Manual - part 577





STR-12

< DTC/CIRCUIT DIAGNOSIS >

B TERMINAL CIRCUIT

DTC/CIRCUIT DIAGNOSIS

B TERMINAL CIRCUIT

Description

INFOID:0000000009886983

Terminal "1" (B) is constantly supplied with battery power.

Diagnosis Procedure

INFOID:0000000009886984

Regarding Wiring Diagram information, refer to

STR-14, "Wiring Diagram"

.

CAUTION:

Before testing, perform the following procedure to ensure the engine cannot start.

1. Remove fuel pump fuse.

2. Crank or start the engine (where possible) until the fuel pressure is depleted.

1.

CHECK TERMINAL 1 POWER SUPPLY VOLTAGE

1. Turn ignition switch OFF.

2. Make sure that starter motor connector F27 terminal 1 connection is clean and tight.

3. Check voltage between starter motor connector F27 terminal 1 and ground.

Is there battery voltage present?

YES

>> GO TO 2

NO

>> Check harness between battery and starter motor for open circuit.

2.

CHECK BATTERY CABLE (VOLTAGE DROP TEST)

1. Shift the transmission into park or neutral.

2. Check voltage between battery positive terminal and starter motor connector F27 terminal 1 while crank-

ing the engine.

Is the voltage drop less than 0.2V?

YES

>> GO TO 3

NO

>> Check harness between the battery and the starter motor for high resistance.

3.

CHECK GROUND CIRCUIT STATUS (VOLTAGE DROP TEST)

Check voltage between starter motor case and battery negative terminal while cranking the engine.

Is the voltage drop less than 0.2V?

YES

>> Terminal 1 circuit is OK. Further inspection is necessary. Refer to

STR-4, "Work Flow (With GR8-

1200 NI)"

 or

STR-8, "Work Flow (Without GR8-1200 NI)"

.

NO

>> Check the starter motor case to engine mounting for high resistance.

(+)

(-)

Voltage

Connector

Terminal

F27

1

Ground

Battery voltage

(+)

(-)

Condition

Voltage

Battery (+) terminal

Connector

Terminal

F27

1

While cranking the engine

Less than 0.2V

(+)

(-)

Condition

Voltage

Starter motor case

Battery (-) terminal

While cranking the engine

Less than 0.2V

S CONNECTOR CIRCUIT

STR-13

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

S CONNECTOR CIRCUIT

Description

INFOID:0000000009886985

Terminal "2" (S) is the power supply for the starter motor magnetic switch. Terminal 2 is supplied with power

when the ignition switch is turned to the START position while the selector lever is in the P or N position.

Diagnosis Procedure

INFOID:0000000009886986

Regarding Wiring Diagram information, refer to

STR-14, "Wiring Diagram"

.

CAUTION:

Before testing, perform the following procedure to ensure the engine cannot start.

1. Remove fuel pump fuse.

2. Crank or start the engine (where possible) until the fuel pressure is released.

1.

CHECK STARTER MOTOR MAGNETIC SWITCH CIRCUIT

1. Turn ignition switch OFF.

2. Disconnect starter motor connector F28.

3. Shift transmission into park or neutral.

4. Check voltage between starter motor harness connector F28 terminal 2 and ground with the ignition in

START.

Is battery voltage present?

YES

>> Magnetic switch circuit is OK. Further inspection is necessary. Refer to

STR-4, "Work Flow (With

GR8-1200 NI)"

 or

STR-8, "Work Flow (Without GR8-1200 NI)"

.

NO

>> GO TO 2

2.

CHECK CONNECTOR

1. Turn ignition switch OFF.

2. Check the IPDM E/R harness connector E120 and starter motor harness connector F28 for damage, bent

pins and loose connections.

Is the inspection result normal?

YES

>> GO TO 3

NO

>> Repair the terminal and connector.

3.

CHECK HARNESS CONTINUITY (OPEN CIRCUIT)

1. Disconnect IPDM E/R connector E120 and starter motor connector F28.

2. Check continuity between starter motor harness connector F28 terminal 2 and IPDM E/R harness connec-

tor E120 terminal 19.

3. Check continuity between starter motor harness connector F28 terminal 2 and ground.

Are the continuity test results as specified?

YES

>> Further inspection is necessary. Refer to

STR-4, "Work Flow (With GR8-1200 NI)"

 or

STR-8,

"Work Flow (Without GR8-1200 NI)"

.

NO

>> Repair the harness.

(+)

(-)

Condition

Voltage

Connector

Terminal

F28

2

Ground

Ignition in START

Battery voltage

Connector

Terminal

Connector

Terminal

Continuity

F28

2

E120

19

Yes

Connector

Terminal

Continuity

F28

2

Ground

No

STR-14

< WIRING DIAGRAM >

STARTING SYSTEM

WIRING DIAGRAM

STARTING SYSTEM

Wiring Diagram

INFOID:0000000009886987

ABBWA0928GB

STARTING SYSTEM

STR-15

< WIRING DIAGRAM >

C

D

E

F

G

H

I

J

K

L

M

A

STR

N

P

O

ABBIA1434GB
