P0340 CMP SENSOR (PHASE) EC-277 < DTC/CIRCUIT DIAGNOSIS > [VK56DE] C D E F G H I J K L M A EC N P O 8. If 1st trip DTC is detected, go to Diagnosis Procedure INFOID:0000000009886686 1. CHECK STARTING SYSTEM Turn ignition switch to START position. Yes or No Yes >> GO TO 2. No >> Check starting system. (Refer to STR-19, "Removal and Installation" .) 2. CHECK GROUND CONNECTIONS 1. Turn ignition switch OFF. 2. Loosen and retighten three ground screws on the body. OK or NG OK >> GO TO 3. NG >> Repair or replace ground connections. 3. CHECK CAMSHAFT POSITION (CMP) SENSOR (PHASE) POWER SUPPLY CIRCUIT 1. Disconnect camshaft position (CMP) sensor (PHASE) (2) har- ness connector. - Radiator hose (1) 2. Turn ignition switch ON. 3. Check voltage between CMP sensor (PHASE) terminal 3 and ground with CONSULT or tester. OK or NG OK >> GO TO 5. NG >> GO TO 4. 4. DETECT MALFUNCTIONING PART Check the following. Does the engine turn over? BBIA0354E BBIA0740E Voltage: Battery voltage SEF481Y |
