DLN-268 < UNIT DISASSEMBLY AND ASSEMBLY > [REAR FINAL DRIVE: M226 (ELD) ] REAR FINAL DRIVE 2. Apply multi-purpose grease to new front oil seal lip. Install new front oil seal into gear carrier using Tool. CAUTION: • Do not reuse front oil seal. • Do not incline the new front oil seal when installing. • Apply multi-purpose grease to the lips of the new front oil seal. 3. Install new collapsible spacer on drive pinion assembly. And then install drive pinion assembly into gear carrier. CAUTION: • Do not reuse collapsible spacer. • Do not damage front oil seal. 4. Install a new oil seal/dust shield. the matching marks. Then tap the companion flange using suit- able tool. CAUTION: Do not damage companion flange or front oil seal. Tool number : ST15310000 ( — ) PDIA0326E SDIA2595E PDIA0328E |
