DLN-116 < UNIT DISASSEMBLY AND ASSEMBLY > [TRANSFER: TX15B] TRANSFER ASSEMBLY 41. Install the transfer control device to the rear case. tool, and then put a mark on the control shift rod. b. Align the transfer control device shaft cutout with the mark on the control shift rod, and install it. NOTE: Turn the transfer control device when the transfer control device connection does not match. c. Tighten the bolts to the specified torque. Refer to 42. Install the drain plug and filler plug with new gaskets to the rear case. Tighten to the specified torque. DLN-101, "Disassembly and Assembly" CAUTION: Do not reuse gaskets. PDIA0119E PDIA0120E SDIA2212E |
