Nissan Titan A60. Manual - part 637
AIR CONDITIONER CONTROL
HAC-231
< ECU DIAGNOSIS INFORMATION >
[MANUAL A/C (TYPE 2)]
C
D
E
F
G
H
J
K
L
M
A
B
HAC
N
O
P
*1: If equipped
24
BR
Illumination -
-
Park lamps ON
25
LG/B
Defroster door motor feedback
ON
-
0 - 5V
26
R/B
Front blower request
ON
Front blower motor OFF
Battery voltage
Front blower motor ON
0V
29
Y/L
Water valve
ON
Water valve open
Battery voltage
Water valve closed
0V
30
W/G
Water valve
ON
Water valve open
0V
Water valve closed
Battery voltage
34
L
CAN-H
ON
-
0 - 5V
35
P
CAN-L
ON
-
0 - 5V
36
L/R
Fan ON signal
ON
Blower switch OFF
5V
ON
Blower switch ON
0V
40
G/R
Variable blower control
ON
-
0 - 5V
Terminal
No.
Wire
color
Item
Ignition
switch
Condition
Voltage (V)
(Approx.)
PIIA2344E
