Nissan Titan A60. Manual - part 523
HIGH-MOUNTED STOP LAMP
EXL-147
< REMOVAL AND INSTALLATION >
C
D
E
F
G
H
I
J
K
M
A
B
EXL
N
O
P
HIGH-MOUNTED STOP LAMP
Bulb Replacement
INFOID:0000000006179087
HIGH-MOUNTED STOP LAMP
Removal
1. Remove the high-mounted stop lamp. Refer to
EXL-147, "Removal and Installation"
2. Turn bulb socket counter clockwise to remove it from lamp housing.
3. Pull bulb from socket.
Installation
Installation is in the reverse order of removal.
Removal and Installation
INFOID:0000000006179088
HIGH-MOUNTED STOP LAMP
Removal
1. Remove high-mounted stop lamp access covers(3).
2. Disconnect high-mounted stop lamp electrical connector.
3. Remove high-mounted stop lamp nuts(2).
4. Remove high-mounted stop lamp(1).
Installation
Installation is in the reverse order of removal.
WKIA4686E
