DIFF LOCK INDICATOR LAMP FLASHES WHILE DRIVING DLN-247 < SYMPTOM DIAGNOSIS > [REAR FINAL DRIVE: M226 (ELD) ] C E F G H I J K L M A B DLN N O P DIFF LOCK INDICATOR LAMP FLASHES WHILE DRIVING Description INFOID:0000000006179617 The DIFF LOCK indicator lamp will flash once every 2 seconds when the differential lock system is in standby condition. Standby condition is the time between when the differential lock mode switch is turned ON and when the differential lock control unit see’s all conditions are met to engage the differential lock. The DIFF LOCK indicator lamp should be OFF if there has been a fault detected. For more information regarding the dif- ferential lock system operation, refer to the Owner’s Manual. Inspection Procedure INFOID:0000000006179618 SYMPTOM: DIFF LOCK indicator lamp sometimes flashes while driving. DIAGNOSTIC PROCEDURE 1. CHECK SELF-DIAGNOSTIC RESULTS Perform self-diagnosis. Refer to DLN-216, "CONSULT-III Function (DIFF LOCK)" Is any malfunction detected by self-diagnosis? YES >> Check the malfunctioning system. Refer to . NO >> GO TO 2. 2. CHECK DIFFERENTIAL LOCK MODE SWITCH Perform trouble diagnosis for differential lock mode switch. Refer to DLN-224, "Diagnosis Procedure" . Is the inspection result normal? YES >> Condition is intermittent. Refer to GI-39, "Intermittent Incident" . NO >> Repair or replace malfunctioning component. |
