DIFFERENTIAL LOCK CONTROL UNIT DLN-239 < ECU DIAGNOSIS INFORMATION > [REAR FINAL DRIVE: M226 (ELD) ] C E F G H I J K L M A B DLN N O P DTC Index INFOID:0000000006179614 CAUTION: If “CAN COMM CIRCUIT [U1000]” is displayed with other DTCs, first perform the trouble diagnosis for CAN communication Items (CONSULT-III screen terms) Diagnostic item is detected when... Check item INITIAL START Due to removal of battery which cuts off power supply to differential CONTROL UNIT 1 Malfunction is detected in the memory (RAM) system of differential CONTROL UNIT 2 Malfunction is detected in the memory (ROM) system of differential CONTROL UNIT 3 Malfunction is detected in the memory (EEPROM) system of differ- CONTROL UNIT 4 AD converter system of differential lock control unit is malfunctioning. ON SW More than two switch inputs are simultaneously detected due to POSI SW ON When differential lock position switch is ON, rotation difference oc- RELAY Differential lock control unit detects as irregular by comparing target SOL CIRCUIT Malfunction is detected in differential lock control unit internal circuit. SOL DISCONNECT • Differential lock solenoid internal circuit or harness is open. SOL SHORT Differential lock solenoid internal circuit or harness is shorted. SOL CURRENT Differential lock solenoid relay does not switch to OFF position. ABS SYSTEM Malfunction related to wheel sensor has been detected by ABS ac- CAN COMM CIRCUIT Malfunction has been detected from CAN communication line. |
