Nissan Titan A60. Manual - part 90





AV

AUXILIARY INPUT JACK

AV-185

< REMOVAL AND INSTALLATION >

[PREMIUM WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

AUXILIARY INPUT JACK

Removal and Installation

INFOID:0000000006713611

Removal

1. Remove the Cluster lid D. Refer to

IP-15, "Removal and Installation"

.

2. Remove the auxiliary input jack.

Installation

Installation is in the reverse order of removal.

AV-186

< REMOVAL AND INSTALLATION >

[PREMIUM WITHOUT NAVIGATION]

SATELLITE RADIO ANTENNA

SATELLITE RADIO ANTENNA

Removal and Installation

INFOID:0000000006166547

SATELLITE RADIO ANTENNA

Removal

1. Lower the headliner. Refer to

INT-21, "Removal and Installa-

tion"

.

2. Disconnect the satellite radio antenna connector.
3. Remove the satellite radio antenna nut.
4. Remove the satellite radio antenna.

Installation

Installation is in the reverse order of removal.

LKIA0679E

AV

SATELLITE RADIO TUNER

AV-187

< REMOVAL AND INSTALLATION >

[PREMIUM WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SATELLITE RADIO TUNER

Removal and Installation

INFOID:0000000006166548

SATELLITE RADIO TUNER

Removal

1. Remove the accelerator pedal assembly. Refer to

ACC-3, "Removal and Installation"

.

2. Remove the BCM. Refer to

BCS-53, "Removal and Installation"

.

3. Disconnect the audio amp. and the satellite radio tuner connectors.
4. Remove the audio amp./satellite radio tuner bracket screws and

slide the audio amp./satellite radio tuner bracket down.

5. Remove the satellite radio tuner screws (A) and remove the sat-

ellite radio tuner from the audio amp./satellite radio tuner

bracket (1).

Installation

Installation is in the reverse order of removal.

WKIA1605E

LKIA0677E

AV-188

< REMOVAL AND INSTALLATION >

[PREMIUM WITHOUT NAVIGATION]

MICROPHONE

MICROPHONE

Removal and Installation

INFOID:0000000006166549

REMOVAL

1. Remove the front roof console finisher. Refer to

IP-12, "Removal

and Installation"

.

2. Disconnect the Bluetooth microphone connector (A).
3. Detach the Bluetooth microphone (1) from the front roof console

finisher and remove the Bluetooth microphone (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0275ZZ

ALNIA0274ZZ
