BLUETOOTH CONTROL UNIT
Reference Value
INFOID:0000000006166532
TERMINAL LAYOUT
PHYSICAL VALUES
AWNIA1628ZZ
Terminal
(wire color)
Description
Condition
Reference value
(Approx.)
+
–
Signal name
Input/
output
1
(Y)
Ground Battery power
Input
–
–
Battery voltage
2
(V)
Ground ACC power
Input
Ignition
switch
ACC/ON
–
Battery voltage
3
(G/R)
Ground IGN power
Input
Ignition
switch
ON/
START
–
Battery voltage
4
(B/W)
Ground Ground
–
Ignition
switch
ON
–
0V
6
–
Shield
–
–
–
–
7
(B)
8
(R/L)
MIC in signal
Input
–
–
–
9
(G)
10
(R)
Audio out
Output
Ignition
switch
ACC/ON
Bluetooth control
unit sends audio
signal
11
(Y)
–
Mute control
–
–
–
–
12
(R/G)
14
(Y/R)
Steering switch
signal A
Input
Ignition
switch
ON
Pressing
switch
0V
Pressing
switch
0.75
Pressing VOL up
switch
2V
Except for above
5V
