Nissan Titan A60. Manual - part 80

AV

SATELLITE RADIO TUNER

AV-145

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

30

(W/L)

Ground

Communication signal
(CONT

→SAT)

Input

Ignition

switch

ON

When satellite radio mode
is selected

32

(Y)

Ground Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

36

(V)

Ground ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

37

(B)

—

Satellite antenna

Input

—

—

—

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIA9301J

AV-146

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITHOUT NAVIGATION]

AUDIO AMP

AUDIO AMP

Reference Value

INFOID:0000000006166531

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA1623ZZ

Terminal

(wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

1

 (Y)

Ground

Battery

Input

–

–

Battery voltage

2

 (W)

18

(B)

Subwoofer

Output

Ignition

switch

ON

Receive audio sig-
nal

3

(BR/W)

19

(BR)

Subwoofer

Output

Ignition

switch

ON

Receive audio sig-
nal

4

 (B)

Ground

Ground

–

Ignition

switch

ON

–

–

9

(G/W)

Ground

Amp. ON signal

Input

Ignition

switch

ON

–

More than 6.5V

10

 (L/W)

26

(L/B)

Center speaker

Output

Ignition

switch

ON

Receive audio sig-
nal

SKIA0177E

SKIA0177E

SKIA0177E

AV

AUDIO AMP

AV-147

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITHOUT NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

11

(SB)

27

 (B/Y)

Rear door speak-
er LH and rear
door tweeter LH

Output

Ignition

switch

ON

Receive audio sig-
nal

12

(O/L)

28

(R/L)

Rear door speak-
er RH and rear
door tweeter RH

Output

Ignition

switch

ON

Receive audio sig-
nal

13

 (W/B)

29

(L/B)

Front door tweet-
er RH

Output

Ignition

switch

ON

Receive audio sig-
nal

14

(L/W)

30

(L/R)

Front tweeter LH

Output

Ignition

switch

ON

Receive audio sig-
nal

15

(L/W)

31

(L/R)

Front door speak-
er LH

Output

Ignition

switch

ON

Receive audio sig-
nal

16

(W/B)

32

(L/B)

Front door speak-
er RH

Output

Ignition

switch

ON

Receive audio sig-
nal

17

(Y/G)

Ground

Battery

Input

–

–

Battery voltage

20

(B)

Ground

Ground

–

Ignition

switch

ON

–

–

Terminal

(wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

AV-148

< ECU DIAGNOSIS INFORMATION >

[PREMIUM WITHOUT NAVIGATION]

AUDIO AMP

21

 (Y)

5

(BR)

Audio sound sig-
nal front RH

Input

Ignition

switch

ON

Receive audio sig-
nal

22

(W)

6

(B)

Audio sound sig-
nal front LH

Input

Ignition

switch

ON

Receive audio sig-
nal

23

(L)

7

(B/W)

Audio sound sig-
nal rear RH

Input

Ignition

switch

ON

Receive audio sig-
nal

24

(BR)

8

(B/R)

Audio sound sig-
nal rear LH

Input

Ignition

switch

ON

Receive audio sig-
nal

Terminal

(wire color)

Item

Signal

input/

output

Condition

Reference value

(Approx.)

+

–

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E
