DRIVER SEAT CONTROL UNIT, AUTOMATIC DRIVE POSITIONER CONTROL

UNIT

ECU DIAGNOSIS INFORMATION

DRIVER SEAT CONTROL UNIT, AUTOMATIC DRIVE POSITIONER CON-
TROL UNIT

List of ECU Reference

INFOID:0000000009652708

ECU

Reference

DRIVER SEAT CONTROL UNIT

ADP-25, "Reference Value"

ADP-30, "Fail-safe"

ADP-30, "DTC Index"

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

ADP-31, "Reference Value"

DOOR MIRROR SYSTEM

MIR-13

< WIRING DIAGRAM >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

WIRING DIAGRAM

DOOR MIRROR SYSTEM

Wiring Diagram

INFOID:0000000009652709

JCLWA5123GB

MIR-14

< WIRING DIAGRAM >

[WITH ADP]

DOOR MIRROR SYSTEM

JCLWA5124GB

DOOR MIRROR SYSTEM

MIR-15

< WIRING DIAGRAM >

[WITH ADP]

C

D

E

F

G

H

I

J

K

M

A

B

MIR

N

O

P

JRLWC7424GB
