FOREWORD

This manual contains maintenance and repair procedure for the 2014
NISSAN QUEST.

In order to assure your safety and the efficient functioning of the vehicle,
this manual should be read thoroughly. It is especially important that the
PRECAUTIONS in the GI section be completely understood before starting
any repair task.

All information in this manual is based on the latest product information
at the time of publication. The right is reserved to make changes in specifi-
cations and methods at any time without notice.

IMPORTANT SAFETY NOTICE

The proper performance of service is essential for both the safety of
the technician and the efficient functioning of the vehicle.
The service methods in this Service Manual are described in such a
manner that the service may be performed safely and accurately.
Service varies with the procedures used, the skills of the technician
and the tools and parts available. Accordingly, anyone using service
procedures, tools or parts which are not specifically recommended
by NISSAN must first be completely satisfied that neither personal
safety nor the vehicle’s safety will be jeopardized by the service
method selected.

PLEASE HELP MAKE THIS SERVICE MANUAL BETTER!

Your comments are important to NISSAN and will help us to improve our Service Manuals.
Use this form to report any issues or comments you may have regarding our Service Manuals.
Please print this form and type or write your comments below. Mail or fax to:

Nissan North America, Inc.
Technical Service Information
39001 Sunrise Drive, P.O. Box 9200
Farmington Hills, MI USA 48331
FAX: (248) 488-3880

SERVICE MANUAL: Model:

Year:

PUBLICATION NO. (Refer to Quick Reference Index ):
Please describe any Service Manual issues or problems in detail:
Page number(s)

Note: Please include a copy of each page, marked with your comments.

Are the trouble diagnosis procedures logical and easy to use? (circle your answer)

YES

If no, what page number(s)?

Note: Please include a copy of each page, marked with your comments.

Please describe the issue or problem in detail:

Is the organization of the manual clear and easy to follow? (circle your answer)

YES

Please comment:

What information should be included in NISSAN Service Manuals to better support you in servicing or
repairing customer vehicles?

DATE:

YOUR NAME:

POSITION:

DEALER:

DEALER NO.:

ADDRESS:

CITY:

STATE/PROV./COUNTRY:

ZIP/POSTAL CODE:

QUICK REFERENCE CHART QUEST

PFP:00000

ENGINE TUNE-UP DATA (VQ35DE)

ELS0003W

Engine model

VQ35DE

Firing order

1-2-3-4-5-6

Idle speed
CVT (In “P” or “N” position)

rpm

650 ± 50

Ignition timing (BTDC at idle speed)
CVT (In “P” or “N” position)

± 2

Tensions of drive belt

Belt tension is not necessary, as it is automatically adjusted by

drive belt auto-tensioner.

Radiator cap relief pressure

kPa (kg/cm

, psi)

Standard

122.3 - 151.7 (1.2 - 1.5, 17.7 - 22.0)

Limit

108 (1.1, 15.6)

Cooling system leakage testing pressure

kPa (kg/cm

, psi)

156 (1.59, 22.6)

Compression pressure

kPa (kg/cm

, psi)/rpm

Standard

1,275 (13.0, 185)/300

Minimum

981 (10.0, 142)/300

Spark plug

Make

DENSO

Standard type

FXE22HR11

Gap

Standard

1.1 mm (0.043 in)

Limit

1.4 mm (0.055 in)

2014
