B C S

BCM

BCS-55

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

53*

5

(BR)

Ground

Back door open re-
quest

Output

Back door
opener switch

OFF (Actuator is not acti-
vated)

9 – 16 V

ON   (Actuator is activat-
ed)

0 – 1.5 V

(Approx. 500m seconds)

54

(R)

Ground

Rear wiper

Output

Rear wiper

OFF (Stopped)

0 V

ON (Activated)

9 – 16 V

55

(G)

Ground

Sliding door RH UN-
LOCK (with auto-
matic sliding door
system)

Output

Sliding door RH

UNLOCK (Actuator is acti-
vated)

9 – 16 V

Other then UNLOCK (Ac-
tuator is not activated)

0 V

Sliding door UN-
LOCK (without auto-
matic sliding door
system)

Sliding door

UNLOCK (Actuator is acti-
vated)

9 – 16 V

Other then UNLOCK (Ac-
tuator is not activated)

0 V

56

(P)

Ground

Interior room lamp
power supply

Output

Interior room lamp battery saver is activated.
(Cuts the interior room lamp power supply)

0 V

Interior room lamp battery saver is not acti-
vated.
(Outputs the interior room lamp power sup-
ply)

9 – 16 V

57

(GR)

Ground

Battery power sup-
ply

Input

Ignition switch OFF

9 – 16 V

58

(O)

Ground

Air bag signal

Input

Ignition switch

OFF

5 V

ON

2.5 V

59

(SB)

Ground

Passenger door UN-
LOCK

Output

Passenger door

UNLOCK (Actuator is acti-
vated)

9 – 16 V

Other then UNLOCK (Ac-
tuator is not activated)

0 V

60

(V)

Ground

Turn signal LH

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch LH

6.5 V

(Turn signal lamp turn on: 9 - 16

V)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA1034GB

PKIC6370E

BCS-56

< ECU DIAGNOSIS INFORMATION >

BCM

61

(G)

Ground

Turn signal RH

Output

Ignition switch
ON

Turn signal switch OFF

0 V

Turn signal switch RH

6.5 V

(Turn signal lamp turn on: 9 - 16

V)

62

(W)

Ground

Step lamp

Output

Step lamp

ON

0 – 1.0 V

OFF

9 – 16 V

63

(R)

Ground

Interior room lamp
control

Output

Interior room
lamp

OFF

9 – 16 V

ON

0 – 1.0 V

64

(LG)

Ground

Cranking request

input

Ignition switch
ON

Engine stopped (Selector
lever is in P position)

0 – 1.0 V

Engine stopped (Selector
lever is not in P position)

9 – 16 V

Engine running

9 – 16 V

65

(V)

Ground

All doors LOCK

Output

All doors

LOCK (Actuator is activat-
ed)

9 – 16 V

Other then LOCK (Actua-
tor is not activated)

0 V

66

(G)

Ground

Driver door UN-
LOCK

Output

Driver door, fuel
lid

UNLOCK (Actuator is acti-
vated)

9 – 16 V

Other then UNLOCK (Ac-
tuator is not activated)

0 V

67

(B)

Ground

Ground

Output

Ignition switch ON

0 V

68

(L)

Ground

P/W power supply
(IGN)

Output

Ignition switch OFF

0 V

Ignition switch ON

9 – 16 V

69

(P)

Ground

P/W power supply
(BAT)

Output

Ignition switch OFF

9 – 16 V

70

(L)

Ground

Battery power sup-
ply

Input

Ignition switch OFF

9 – 16 V

73

(Y)

Ground

ON indicator lamp

Output

Ignition switch

OFF (LOCK indicator is
not illuminated)

9 – 16 V

ON

0 – 1.5 V

75

(SB)

Ground

Driver door request
switch

Input

Driver door re-
quest switch

ON (Pressed)

0 – 1.5 V

OFF (Not pressed)

9 – 16 V

76

(V)

Ground

Push-button ignition
switch (push switch)

Input

Push-button ig-
nition switch
(push switch)

Pressed

0 – 1.5 V

Not pressed

9 – 16 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIC6370E

BCS

BCM

BCS-57

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

78

(P)

Ground

Driver door antenna
(+)

Output

When the driver
door request
switch is operat-
ed with ignition
switch ON

When Intelligent Key is
not in the antenna detec-
tion area
(The distance between In-
telligent Key and antenna:
Approx. 2 m)

When Intelligent Key is in
the antenna detection
area
(The distance between In-
telligent Key and antenna:
80 cm or less)

79

(V)

Ground

Driver door antenna
(-)

Output

When the driver
door request
switch is operat-
ed with ignition
switch ON

When Intelligent Key is
not in the antenna detec-
tion area
(The distance between In-
telligent Key and antenna:
Approx. 2 m)

When Intelligent Key is in
the antenna detection
area
(The distance between In-
telligent Key and antenna:
80 cm or less)

80

(R)

Ground

Passenger door an-
tenna (+)

Output

When the pas-
senger door re-
quest switch is
operated with
ignition switch
ON

When Intelligent Key is
not in the antenna detec-
tion area
(The distance between In-
telligent Key and antenna:
Approx. 2 m)

When Intelligent Key is in
the antenna detection
area
(The distance between In-
telligent Key and antenna:
80 cm or less)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA5954GB

JMKIA5955GB

JMKIA5954GB

JMKIA5955GB

JMKIA5954GB

JMKIA5955GB

BCS-58

< ECU DIAGNOSIS INFORMATION >

BCM

81

(L)

Ground

Passenger door an-
tenna (-)

Output

When the pas-
senger door re-
quest switch is
operated with
ignition switch
ON

When Intelligent Key is
not in the antenna detec-
tion area
(The distance between In-
telligent Key and antenna:
Approx. 2 m)

When Intelligent Key is in
the antenna detection
area
(The distance between In-
telligent Key and antenna:
80 cm or less)

82

(G)

Ground

Rear bumper anten-
na (+)

Output

When the back
door request
switch is operat-
ed with ignition
switch ON

When Intelligent Key is
not in the antenna detec-
tion area
(The distance between In-
telligent Key and antenna:
Approx. 2 m)

When Intelligent Key is in
the antenna detection
area
(The distance between In-
telligent Key and antenna:
80 cm or less)

83

(R)

Ground

Rear bumper anten-
na (-)

Output

When the back
door request
switch is operat-
ed with ignition
switch ON

When Intelligent Key is
not in the antenna detec-
tion area
(The distance between In-
telligent Key and antenna:
Approx. 2 m)

When Intelligent Key is in
the antenna detection
area
(The distance between In-
telligent Key and antenna:
80 cm or less)

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA5954GB

JMKIA5955GB

JMKIA5954GB

JMKIA5955GB

JMKIA5954GB

JMKIA5955GB
