COLLISION DIAGNOSIS
SR-9
< BASIC INSPECTION >
C
D
E
F
G
I
J
K
L
M
A
B
SR
N
O
P
• If the door finisher assembly is damaged, the door finisher assembly and door-mounted curtain air bag
module must be replaced.
3.
Perform self-diagnosis using CONSULT and “AIR BAG” warning lamp. Refer to
SRC-15, "On Board Diagnosis Function"
for details. Make sure entire SRS operates properly.
4.
After the work is completed, perform self-diagnosis to check that no malfunction is detected. Refer to
.
SRS INSPECTION (FOR SIDE AND ROLLOVER COLLISION)
Part
Inspection
Curtain air bag module LH
If the curtain air bag LH has NOT deployed:
1.
Check for visible signs of damage (dents, tears, deformation, etc.) of the center pillar on the col-
lision side.
2.
If damaged
−
Remove the curtain air bag module LH.
3.
Check for visible signs of damage (tears etc.) of the curtain air bag module LH.
4.
Check harness and connectors for damage, and terminals for deformities.
5.
If no damage is found, reinstall the curtain air bag module LH with new fasteners.
6.
If damaged
−
REPLACE the curtain air bag module LH with new fasteners.
CAUTION:
Before disposing of such systems, deploy the systems.
Curtain air bag module RH
If the curtain air bag RH has NOT deployed:
1.
Check for visible signs of damage (dents, tears, deformation, etc.) of the center pillar on the col-
lision side.
2.
If damaged
−
Remove the curtain air bag module RH.
3.
Check for visible signs of damage (tears etc.) of the curtain air bag module RH.
4.
Check harness and connectors for damage, and terminals for deformities.
5.
If no damage is found, reinstall the curtain air bag module RH with new fasteners.
6.
If damaged
−
REPLACE the curtain air bag module RH with new fasteners.
CAUTION:
Before disposing of such systems, deploy the systems.
Side air bag module LH
If the side air bag LH has NOT deployed:
1.
Check for visible signs of damage (dents, tears, deformation, etc.) of the seat back on the col-
lision side.
2.
Check harness and connectors for damage, and terminals for deformities.
3.
If damaged
−
REPLACE the front seatback assembly LH.
CAUTION:
Before disposing of such systems, deploy the systems.
Side air bag module RH
If the side air bag RH has NOT deployed:
1.
Check for visible signs of damage (dents, tears, deformation, etc.) of the seat back on the col-
lision side.
2.
Check harness and connectors for damage, and terminals for deformities.
3.
If damaged
−
REPLACE the front seatback assembly RH.
CAUTION:
Before disposing of such systems, deploy the systems.
Satellite sensor (LH or RH)
If none of the SRS components have been activated:
1.
Remove the satellite sensor (LH or RH) on the collision side. Check harness connectors for
damage, terminals for deformities, and harness for binding.
2.
Check for visible signs of damage (dents, cracks, deformation, etc.) of the satellite sensor (LH
or RH).
3.
Install the satellite sensor (LH or RH) to check fit.
4.
If no damage is found, reinstall the side sir bag (satellite) sensor (LH or RH) with new fasteners.
5.
If damaged
−
REPLACE the satellite sensor (LH or RH) with new fasteners.
Diagnosis sensor unit
If none of the SRS components have been activated:
1.
Check case and bracket for dents, cracks or deformities.
2.
Check connectors for damage, and terminals for deformities.
3.
If no damage is found, reinstall the diagnosis sensor unit with new fasteners.
4.
If damaged
−
REPLACE the diagnosis sensor unit with new fasteners.
