BCM (BODY CONTROL MODULE)
SEC-227
< ECU DIAGNOSIS INFORMATION >
[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
M
A
B
SEC
N
O
P
FR WIPER INT
Front wiper switch OFF
Off
Front wiper switch INT
On
FR WASHER SW
Front washer switch OFF
Off
Front washer switch ON
On
INT VOLUME
Wiper intermittent dial is in a dial position 1 - 7
1 - 7
FR WIPER STOP
Any position other than front wiper stop position
Off
Front wiper stop position
On
RR WIPER ON
Rear wiper switch OFF
Off
Rear wiper switch ON
On
RR WIPER INT
Rear wiper switch OFF
Off
Rear wiper switch INT
On
RR WASHER SW
Rear washer switch OFF
Off
Rear washer switch ON
On
RR WIPER STOP
Rear wiper stop position
Off
Other than rear wiper stop position
On
RAIN SENSOR
NOTE:
The item is indicated, but not monitored.
Off
HAZARD SW
Hazard switch OFF
Off
Hazard switch ON
On
FAN ON SIG
Blower control dial OFF
Off
Other than blower control dial OFF
On
AIR COND SW
A/C switch OFF
Off
A/C switch ON
On
THERMO AMP
Ignition switch ON
Off
Evaporator is extremely low temperature
On
FR DEF SW
Other than A/C mode defroster ON position
Off
A/C mode defroster ON position
On
KEYLESS TRUNK
NOTE:
The item is indicated, but not monitored.
Off
TRNK OPNR SW
NOTE:
The item is indicated, but not monitored.
Off
TRNK OPN MNTR
NOTE:
The item is indicated, but not monitored.
Off
HOOD SW
Close the hood
Off
Open the hood
On
TRANSPONDER
Other than the ignition switch is ON by key registered to BCM.
Off
The ignition switch is ON by key registered to BCM.
On
INTELLI KEY
NOTE:
The item is indicated, but not used.
Off
AUTO RELOCK
NOTE:
The item is indicated, but not monitored.
Off
OIL PRESS SW
• Ignition switch OFF or ACC
• Engine running
Off
Ignition switch ON
On
BRAKE SW
Brake pedal is not depressed
Off
Brake pedal is depressed
On
Monitor Item
Condition
Value/Status
