BCM (BODY CONTROL MODULE)

PWC-41

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

PWC

N

O

P

29

(L/W)

Ground

Hazard switch

Input

Hazard switch

OFF

12 V

ON

0 V

31

(G/B)

Ground

Front door lock as-
sembly driver side
(Unlock sensor)

Input

Driver door

LOCK status (Unlock sen-
sor switch OFF)

7.0 - 8.0 V

UNLOCK status (Unlock
sensor switch ON)

0 V

32

(LG)

Ground

Combination switch
OUTPUT 5

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Front fog lamp switch ON
(Wiper intermittent dial 4)

1.0 V

Rear wiper switch ON
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 6
• Wiper intermittent dial 7

33

(Y/L)

Ground

Combination switch
OUTPUT 4

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Lighting switch 1ST
(Wiper intermittent dial 4)

1.2 V

Lighting switch AUTO
(Wiper intermittent dial 4)

Rear wiper switch INT
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4960J

PKIB4956J

PKIB4960J

PKIB4958J

PWC-42

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

34

(W)

Ground

Combination switch
OUTPUT 3

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Lighting switch 2ND
(Wiper intermittent dial 4)

1.2 V

Lighting switch HI
(Wiper intermittent dial 4)

Rear washer switch ON
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 3

35

(R/L)

Ground

Combination switch
OUTPUT 2

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

7.0 - 8.0 V

Lighting switch 2ND

1.2 V

Lighting switch PASS

Front wiper switch INT

Front wiper switch HI

36

(L/O)

Ground

Combination switch
OUTPUT 1

Output

Combination
switch
(Wiper intermit-
tent dial 4)

All switch OFF

7.0 - 8.0 V

Turn signal switch RH

1.2 V

Turn signal switch LH

Front wiper switch LO
(Front wiper switch MIST)

Front washer switch ON

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

PKIB4960J

PKIB4958J

BCM (BODY CONTROL MODULE)

PWC-43

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

L

M

A

B

PWC

N

O

P

37

(G/O)

Ground

Selector lever P po-
sition switch

Input

Selector lever

P position

0 V

Any position other than P

12 V

38

(G/Y)

Ground

Receiver communi-
cation

Input/

Output

Ignition switch
OFF (Remote
keyless entry
communication)

Waiting

12 V

When operating either
button on Intelligent Key

Ignition switch
ON (TPMS
communication)

Waiting

When receiving signal
from tire pressure sensor

39

(L)

Ground

CAN-H

Input/

Output

—

—

40

(P)

Ground

CAN-L

Input/

Output

—

—

43

(W)

Ground

Back door switch

Input

Back door
switch

OFF
(When back door closed)

9.5 - 10.0 V

ON
(When back door opened)

0 V

44

(LG)

Ground

Rear wiper stop po-
sition

Input

Ignition switch
ON

Rear wiper stop position

12 V

Any position other than
rear wiper stop position

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

JMMIA0572GB

JMMIA0573GB

JMMIA0574GB

PKIB4960J

PWC-44

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

45

(SB)

Ground

Passenger door
switch

Input

Passenger door
switch

OFF (When passenger
door closed)

7.0 - 8.0 V

ON (When passenger
door opened)

0 V

46

(GR/L)

Ground

Rear RH door switch

Input

Rear RH door
switch

OFF (When rear RH door
closed)

7.0 - 8.0 V

ON (When rear RH door
opened)

0 V

47

(BR/Y)

Ground

Driver door switch

Input

Driver door
switch

OFF (When driver door
closed)

7.0 - 8.0 V

ON (When driver door
opened)

0 V

48

(W/G)

Ground

Rear LH door switch

Input

Rear LH door
switch

OFF (When rear LH door
closed)

7.0 - 8.0 V

ON (When rear door LH
opened)

0 V

50

(R/W)

Ground

Back door lock actu-
ator relay control

Output

Back door

LOCK (Actuator is activat-
ed)

0 V

Other than LOCK (Actua-
tor is not activated)

Battery voltage

51

(W)

Ground

Back door request
switch

Input

Back door re-
quest switch

ON (Pressed)

0 V

OFF (Not pressed)

12 V

54

(LG)

Ground

Rear wiper

Output

Rear wiper

OFF (Stopped)

0 V

ON (Activated)

12 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

−

PKIB4960J

PKIB4960J

PKIB4960J

PKIB4960J
