ENGINE OIL
LU-9
< PERIODIC MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
M
A
LU
N
P
O
3.
Install oil pressure gauge [SST: ST25051001 (J-25695-1)] (A)
and hose [SST: ST25052000 (J-25695-2)] (B).
4.
Start engine and warm it up to normal operating temperature.
5.
Check oil pressure with engine running under no-load.
NOTE:
When engine oil temperature is low, engine oil pressure becomes high.
If difference is extreme, check oil passage and oil pump for oil leakage.
6.
After the inspections, install oil pressure switch as follows:
a.
Remove old liquid gasket adhering to oil pressure switch and engine.
b.
Apply liquid gasket and tighten oil pressure switch to specification.
Use Genuine RTV Silicon Sealant or equivalent. Refer to
GI-22, "Recommended Chemical Prod-
.
c.
Check engine oil level. Refer to
.
d.
After warming up engine, check that there is no leakage of engine oil with running engine.
Draining
INFOID:0000000009950379
WARNING:
• Be careful not to get burned, as engine oil may be hot.
• Prolonged and repeated contact with used engine oil may cause skin cancer. Try to avoid direct skin
contact with used engine oil. If skin contact is made, wash thoroughly with soap or hand cleaner as
soon as possible.
1.
Warm up the engine, and check for engine oil leakage from engine components. Refer to
2.
Stop the engine and wait for 10 minutes.
3.
Loosen oil filler cap.
4.
Remove drain plug and then drain engine oil.
Refilling
INFOID:0000000009950380
1.
Install drain plug with new drain plug washer. Refer to
CAUTION:
Be sure to clean drain plug and install with new drain plug washer.
2.
Refill with new engine oil.
Engine oil specification and viscosity: Refer to
MA-10, "Fluids and Lubricants"
CAUTION:
JPBIA0074ZZ
Engine oil pressure
: Refer to
Tightening torque
: Refer to
.
Tightening torque
: Refer to
.
Engine oil capacity
: Refer to
