Nissan Cube. Manual - part 608





INL-52

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

5

(G)

Ground

Combination switch
INPUT 2

Input

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

0 V

Front washer switch
(Wiper intermittent dial 4)

1.0 V

Rear washer ON
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6

Rear wiper switch ON
(Wiper intermittent dial 4)

0.8 V

6

(L/R)

Ground

Combination switch
INPUT 1

Input

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

0 V

Front wiper switch HI
(Wiper intermittent dial 4)

1.0 V

Rear wiper switch INT
(Wiper intermittent dial 4)

Wiper intermittent dial 3
(All switch OFF)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2

1.9 V

Any of the condition below
with all switch OFF
• Wiper intermittent dial 6
• Wiper intermittent dial 7

0.8 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIB4958J

PKIB4956J

PKIB4958J

PKIB4952J

PKIB4956J

BCM (BODY CONTROL MODULE)

INL-53

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

INL

N

O

P

7

(W/R)

Ground

Door key cylinder
switch UNLOCK

Input

Door key cylin-
der switch

NEUTRAL position

8.0 - 8.5 V

UNLOCK position

0 V

8

(W/B)

Ground

Door key cylinder
switch LOCK

Input

Door key cylin-
der switch

NEUTRAL position

12 V

LOCK position

0 V

9

(R)

Ground

Stop lamp switch 1

Input

Stop lamp
switch

OFF (Brake pedal is not
depressed)

0 V

ON (Brake pedal is de-
pressed)

Battery voltage

12

(GR)

Ground

Door lock and unlock
switch LOCK

Input

Door lock and
unlock switch

NEUTRAL position

1.0 - 1.5 V

LOCK position

0 V

13

(BR)

Ground

Door lock and unlock
switch UNLOCK

Input

Door lock and
unlock switch

NEUTRAL position

1.0 - 1.5 V

UNLOCK position

0 V

14

(L/G)

Ground

Optical sensor

Input

Ignition switch
ON

When bright outside of the
vehicle

Close to 5 V

When dark outside of the
vehicle

Close to 0 V

15

(W/L)

Ground

Rear window defog-
ger switch

Input

Rear window
defogger switch

Not pressed

1.0 - 1.5 V

Pressed

0 V

17

(R/G)

Ground

Optical sensor pow-
er supply

Output

Ignition switch

OFF, ACC

0 V

ON

5 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JPMIA0587GB

JPMIA0012GB

JPMIA0012GB

JPMIA0012GB

INL-54

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

18

(V)

Ground

Sensor ground

Input

Ignition switch ON

0 V

21

(P/L)

Ground

NATS antenna amp.

Input/

Output

Intelligent Key:
Intelligent Key
battery is re-
moved

Brake pedal: Depressed
NOTE:
Waveform varies each
time when brake pedal is
depressed

Brake pedal: Not de-
pressed

12 V

23

(R/Y)

Ground

Security indicator
lamp

Output

Security indica-
tor

ON

0 V

Blinking (Ignition switch
OFF)

12.0 V

OFF

Battery voltage

25

(LG)

Ground

NATS antenna amp.

Input/

Output

During waiting

Brake pedal: Depressed
NOTE:
Waveform varies each
time when brake pedal is
depressed

Brake pedal: Not de-
pressed

12 V

27

(O)

Ground

A/C ON

Input

A/C

OFF (A/C switch indicator:
OFF)

1.0 - 1.5 V

ON (A/C switch indicator:
ON)

0 V

28

(G/W)

Ground

Blower fan switch

Input

Fan switch

Blower fan switch OFF

0 V

Blower fan switch ON

7.0 - 8.0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

JMKIA6232JP

JPMIA0590GB

JMKIA6233JP

JPMIA0012GB

PKIB4960J

BCM (BODY CONTROL MODULE)

INL-55

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

INL

N

O

P

29

(L/W)

Ground

Hazard switch

Input

Hazard switch

OFF

12 V

ON

0 V

31

(G/B)

Ground

Front door lock as-
sembly driver side
(Unlock sensor)

Input

Driver door

LOCK status (Unlock sen-
sor switch OFF)

7.0 - 8.0 V

UNLOCK status (Unlock
sensor switch ON)

0 V

32

(LG)

Ground

Combination switch
OUTPUT 5

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Front fog lamp switch ON
(Wiper intermittent dial 4)

1.0 V

Rear wiper switch ON
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 2
• Wiper intermittent dial 6
• Wiper intermittent dial 7

33

(Y/L)

Ground

Combination switch
OUTPUT 4

Output

Combination
switch

All switch OFF
(Wiper intermittent dial 4)

7.0 - 8.0 V

Lighting switch 1ST
(Wiper intermittent dial 4)

1.2 V

Lighting switch AUTO
(Wiper intermittent dial 4)

Rear wiper switch INT
(Wiper intermittent dial 4)

Any of the condition below
with all switch OFF
• Wiper intermittent dial 1
• Wiper intermittent dial 5
• Wiper intermittent dial 6

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

Signal name

Input/

Output

+

PKIB4960J

PKIB4960J

PKIB4956J

PKIB4960J

PKIB4958J
