Nissan Cube. Manual - part 606





INL-44

< DTC/CIRCUIT DIAGNOSIS >

ILLUMINATION

JRLWD0836GB

BCM (BODY CONTROL MODULE)

INL-45

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

INL

N

O

P

ECU DIAGNOSIS INFORMATION

BCM (BODY CONTROL MODULE)

WITH INTELLIGENT KEY

WITH INTELLIGENT KEY : Reference Value

INFOID:0000000010262818

VALUES ON THE DIAGNOSIS TOOL

NOTE:
The following table includes information (items) inapplicable to this vehicle. For information (items) applicable
to this vehicle, refer to CONSULT display items.

CONSULT MONITOR ITEM

Monitor Item

Condition

Value/Status

FR WIPER HI

Other than front wiper switch HI

Off

Front wiper switch HI

On

FR WIPER LOW

Other than front wiper switch LO

Off

Front wiper switch LO

On

FR WASHER SW

Front washer switch OFF

Off

Front washer switch ON

On

FR WIPER INT

Other than front wiper switch INT

Off

Front wiper switch INT

On

FR WIPER STOP

Front wiper is not in STOP position

Off

Front wiper is in STOP position

On

INT VOLUME

Wiper intermittent dial is in a dial position 1 - 7

Wiper intermittent dial

position

RR WIPER ON

Other than rear wiper switch ON

Off

Rear wiper switch ON

On

RR WIPER INT

Other than rear wiper switch INT

Off

Rear wiper switch INT

On

RR WASHER SW

Rear washer switch OFF

Off

Rear washer switch ON

On

RR WIPER STOP

Rear wiper is in STOP position

Off

Rear wiper is not in STOP position

On

TURN SIGNAL R

Other than turn signal switch RH

Off

Turn signal switch RH

On

TURN SIGNAL L

Other than turn signal switch LH

Off

Turn signal switch LH

On

TAIL LAMP SW

Other than lighting switch 1ST and 2ND

Off

Lighting switch 1ST or 2ND

On

HI BEAM SW

Other than lighting switch HI

Off

Lighting switch HI

On

HEAD LAMP SW 1

Other than lighting switch 2ND

Off

Lighting switch 2ND

On

HEAD LAMP SW 2

Other than lighting switch 2ND

Off

Lighting switch 2ND

On

PASSING SW

Other than lighting switch PASS

Off

Lighting switch PASS

On

INL-46

< ECU DIAGNOSIS INFORMATION >

BCM (BODY CONTROL MODULE)

AUTO LIGHT SW

Other than lighting switch AUTO

Off

Lighting switch AUTO

On

FR FOG SW

Front fog lamp switch OFF

Off

Front fog lamp switch ON

On

DOOR SW-DR

Driver door closed

Off

Driver door opened

On

DOOR SW-AS

Passenger door closed

Off

Passenger door opened

On

DOOR SW-RR

Rear RH door closed

Off

Rear RH door opened

On

DOOR SW-RL

Rear LH door closed

Off

Rear LH door opened

On

DOOR SW-BK

Back door closed

Off

Back door opened

On

CDL LOCK SW

Other than power door lock switch LOCK

Off

Power door lock switch LOCK

On

CDL UNLOCK SW

Other than power door lock switch UNLOCK

Off

Power door lock switch UNLOCK

On

KEY CYL LK-SW

Other than driver door key cylinder LOCK position

Off

Driver door key cylinder LOCK position

On

KEY CYL UN-SW

Other than driver door key cylinder UNLOCK position

Off

Driver door key cylinder UNLOCK position

On

HAZARD SW

Hazard switch is OFF

Off

Hazard switch is ON

On

REAR DEF SW

Rear window defogger switch OFF

Off

Rear window defogger switch ON

On

TR/BD OPEN SW

NOTE:
The item is indicated, but not monitored.

Off

TRNK/HAT MNTR

NOTE:
The item is indicated, but not monitored.

Off

FAN ON SIG

Blower fan OFF

Off

Blower fan ON

On

AIR COND SW

Air conditioner OFF (A/C switch indicator OFF)

Off

Air conditioner ON (A/C switch indicator ON)

On

RKE-LOCK

LOCK button of the key is not pressed

Off

LOCK button of the key is pressed

On

RKE-UNLOCK

UNLOCK button of the key is not pressed

Off

UNLOCK button of the key is pressed

On

RKE-TR/BD

BACK DOOR OPEN button of the key is not pressed

Off

BACK DOOR OPEN button of the key is pressed

On

RKE-PANIC

PANIC button of the key is not pressed

Off

PANIC button of the key is pressed

On

RKE-MODE CHG

LOCK/UNLOCK button of the key is not pressed and held simultaneously

Off

LOCK/UNLOCK button of the key is pressed and held simultaneously

On

Monitor Item

Condition

Value/Status

BCM (BODY CONTROL MODULE)

INL-47

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

M

A

B

INL

N

O

P

OPTI SEN (DTCT)

Bright outside of the vehicle

Close to 5 V

Dark outside of the vehicle

Close to 0 V

OPTI SEN (FILT)

Bright outside of the vehicle (Lighting switch AUTO)

Close to 5 V

Dark outside of the vehicle (Lighting switch AUTO)

Close to 1.50 V

OPTICAL SENSOR

NOTE:
The item is indicated, but not monitored.

Off

RAIN SENSOR

NOTE:
The item is indicated, but not monitored.

Off

REQ SW -DR

Driver door request switch is not pressed

Off

Driver door request switch is pressed

On

REQ SW -AS

Passenger door request switch is not pressed

Off

Passenger door request switch is pressed

On

REQ SW -RR

NOTE:
The item is indicated, but not monitored.

Off

REQ SW -RL

NOTE:
The item is indicated, but not monitored.

Off

REQ SW -BD/TR

Back door request switch is not pressed

Off

Back door request switch is pressed

On

PUSH SW

Push-button ignition switch (push switch) is not pressed

Off

Push-button ignition switch (push switch) is pressed

On

CLUCH SW

The clutch pedal is not depressed.

Off

The clutch pedal is depressed

On

BRAKE SW 1

The brake pedal is not depressed

Off

The brake pedal is depressed

On

BRAKE SW 2

The brake pedal is depressed when No. 9 fuse is blown

Off

The brake pedal is not depressed when No. 9 fuse is blown, or No. 9 fuse
is normal

On

DETE/CANCL SW

Selector lever in P position

Off

Selector lever in any position other than P

On

SFT PN/N SW

Selector lever in any position other than P and N

Off

Selector lever in P or N position

On

S/L -LOCK

NOTE:
The item is indicated, but not monitored.

Off

S/L -UNLOCK

NOTE:
The item is indicated, but not monitored.

Off

S/L RELAY-F/B

NOTE:
The item is indicated, but not monitored.

Off

UNLK SEN -DR

Driver door is locked

Off

Driver door is unlocked

On

PUSH SW -IPDM

Push-button ignition switch (push-switch) is not pressed

Off

Push-button ignition switch (push-switch) is pressed

On

IGN RLY1 -F/B

Ignition switch in OFF or ACC position

Off

Ignition switch in ON position

On

DETE SW -IPDM

Selector lever in any position other than P

Off

Selector lever in P position

On

SFT PN -IPDM

Selector lever in any position other than P and N

Off

Selector lever in P or N position

On

Monitor Item

Condition

Value/Status
