EXL-30 < SYSTEM DESCRIPTION > DIAGNOSIS SYSTEM (IPDM E/R) (WITH INTELLIGENT KEY SYSTEM) Concept of auto active test • IPDM E/R starts the auto active test with the door switch signals transmitted by BCM via CAN communica- tion. Therefore, the CAN communication line between IPDM E/R and BCM is considered normal if the auto • The auto active test facilitates troubleshooting if any systems controlled by IPDM E/R cannot be operated. Diagnosis chart in auto active test mode JPMIA1486GB Symptom Inspection contents Possible cause Rear window defogger does not operate Perform auto active test. YES BCM signal input circuit NO • Rear window defogger ground circuit • Harness or connector be- tween IPDM E/R and rear • IPDM E/R Any of the following components do not operate • Parking lamps Perform auto active test. YES BCM signal input circuit NO • Lamp or motor cuit • Harness or connector be- tween IPDM E/R and appli- • IPDM E/R A/C compressor does not operate Perform auto active test. YES • A/C amp. signal input circuit between A/C amp. and • CAN communication signal between ECM and IPDM E/ NO • Magnet clutch tween IPDM E/R and mag- • IPDM E/R |
