BCM (BODY CONTROL MODULE)

Fail-safe

INFOID:0000000010254842

FAIL-SAFE CONTROL BY DTC

BCM performs fail-safe control when any DTC are detected.

JRMWE7831GB

BCM (BODY CONTROL MODULE)

DLK-311

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

REAR WIPER MOTOR PROTECTION

BCM detects the rear wiper stopping position according to the rear wiper auto stop signal.
When the rear wiper auto stop signal does not change more than 5 seconds while driving the rear wiper, BCM
stops power supply to protect the rear wiper motor.

Condition of cancellation

1.

Pass more than 1 minute after the rear wiper stop.

2.

Turn rear wiper switch OFF.

3.

Operate the rear wiper switch or rear washer switch.

DTC Inspection Priority Chart

INFOID:0000000010254843

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.

DTC Index

INFOID:0000000010254844

NOTE:

Details of time display

• CRNT: Displays when there is a malfunction now or after returning to the normal condition until turning igni-

tion switch OFF

→

 ON again.

• 1 - 39: Displayed if any previous malfunction is present when current condition is normal. It increases like 1

→

 2

→

 3...38

→

 39 after returning to the normal condition whenever ignition switch OFF

→

 ON. The counter

remains at 39 even if the number of cycles exceeds it. It is counted from 1 again when turning ignition switch
OFF

→

 ON after returning to the normal condition if the malfunction is detected again.

Display contents of CONSULT

Fail-safe

Cancellation

B2190: NATS ANTENNA AMP

Inhibit engine cranking

Erase DTC

B2191: DIFFERENCE OF KEY

Inhibit engine cranking

Erase DTC

B2192: ID DISCORD BCM-ECM

Inhibit engine cranking

Erase DTC

B2193: CHAIN OF BCM-ECM

Inhibit engine cranking

Erase DTC

B2195: ANTI SCANNING

Inhibit engine cranking

Ignition switch ON

→

 OFF

Priority

DTC

1

• U1000: CAN COMM
• U1010: CONTROL UNIT (CAN)

2

• B2190: NATS ANTENNA AMP
• B2191: DIFFERENCE OF KEY
• B2192: ID DISCORD BCM-ECM
• B2193: CHAIN OF BCM-ECM
• B2195: ANTI SCANNING

3

C1735: IGN CIRCUIT OPEN

4

• C1704: LOW PRESSURE FL
• C1705: LOW PRESSURE FR
• C1706: LOW PRESSURE RR
• C1707: LOW PRESSURE RL
• C1708: [NO DATA] FL
• C1709: [NO DATA] FR
• C1710: [NO DATA] RR
• C1711: [NO DATA] RL
• C1716: [PRESSDATA ERR] FL
• C1717: [PRESSDATA ERR] FR
• C1718: [PRESSDATA ERR] RR
• C1719: [PRESSDATA ERR] RL
• C1729: VHCL SPEED SIG ERR

DLK-312

< ECU DIAGNOSIS INFORMATION >

[WITHOUT INTELLIGENT KEY SYSTEM]

BCM (BODY CONTROL MODULE)

CONSULT display

Fail-safe

Tire pressure

monitor warn-

ing lamp ON

Reference

U1000: CAN COMM

—

—

BCS-120

U1010: CONTROL UNIT (CAN)

—

—

BCS-121

B2190: NATS ANTENNA AMP

×

—

SEC-197

B2191: DIFFERENCE OF KEY

×

—

SEC-200

B2192: ID DISCORD BCM-ECM

×

—

SEC-201

B2193: CHAIN OF BCM-ECM

×

—

SEC-202

B2195: ANTI SCANNING

×

—

SEC-203

C1704: LOW PRESSURE FL

—

×

WT-26

C1705: LOW PRESSURE FR

—

×

C1706: LOW PRESSURE RR

—

×

C1707: LOW PRESSURE RL

—

×

C1708: [NO DATA] FL

—

×

WT-28

C1709: [NO DATA] FR

—

×

C1710: [NO DATA] RR

—

×

C1711: [NO DATA] RL

—

×

C1716: [PRESS DATA ERR] FL

—

×

WT-31

C1717: [PRESS DATA ERR] FR

—

×

C1718: [PRESS DATA ERR] RR

—

×

C1719: [PRESS DATA ERR] RL

—

×

C1729: VHCL SPEED SIG ERR

—

×

WT-33

C1735: IGN CIRCUIT OPEN

—

—

BCS-122

DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK SWITCH

DLK-313

< SYMPTOM DIAGNOSIS >

[WITHOUT INTELLIGENT KEY SYSTEM]

C

D

E

F

G

H

I

J

L

M

A

B

DLK

N

O

P

SYMPTOM DIAGNOSIS

DOOR DOES NOT LOCK/UNLOCK WITH DOOR LOCK AND UNLOCK
SWITCH

ALL DOOR

ALL DOOR : Description

INFOID:0000000009950743

All doors do not lock/unlock using door lock and unlock switch.

ALL DOOR : Diagnosis Procedure

INFOID:0000000009950744

1.

CHECK POWER SUPPLY AND GROUND CIRCUIT

Check power supply and ground circuit.
Refer to

DLK-248, "BCM (BODY CONTROL MODULE) : Diagnosis Procedure"

 (BCM).

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair or replace the malfunctioning parts.

2.

CHECK DOOR LOCK AND UNLOCK SWITCH

Check door lock and unlock switch.
• Driver side: Refer to

DLK-252, "DRIVER SIDE : Component Function Check"

.

• Passenger side: Refer to

DLK-254, "PASSENGER SIDE : Component Function Check"

.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace the malfunctioning parts.

3.

CHECK DOOR LOCK ACTUATOR

Check door lock actuator (driver side).
Refer to

DLK-257, "DRIVER SIDE : Component Function Check"

.

Is the inspection result normal?

YES

>> GO TO 4.

NO

>> Repair or replace the malfunctioning parts.

4.

CONFIRM THE OPERATION

Confirm the operation again.

Is the result normal?

YES

>> Check intermittent incident. Refer to

GI-40, "Intermittent Incident"

.

NO

>> GO TO 1.

DRIVER SIDE

DRIVER SIDE : Description

INFOID:0000000009950745

Driver side door does not lock/unlock using door lock and unlock switch.

DRIVER SIDE : Diagnosis Procedure

INFOID:0000000009950746

1.

CHECK DOOR LOCK ACTUATOR

Check door lock actuator (driver side).
Refer to

DLK-257, "DRIVER SIDE : Component Function Check"

.

Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair or replace the malfunctioning parts.

2.

CONFIRM THE OPERATION

Confirm the operation again.
