BRC-94

< ECU DIAGNOSIS INFORMATION >

[VDC/TCS/ABS]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

JRFWC1192GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

BRC-95

< ECU DIAGNOSIS INFORMATION >

[VDC/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

JRFWC1193GB

BRC-96

< ECU DIAGNOSIS INFORMATION >

[VDC/TCS/ABS]

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

Fail-Safe

INFOID:0000000009950027

VDC, TCS

If VDC/TCS/ABS system malfunction electrically, VDC warning lamp are turned ON, and the condition of vehi-
cle is the same as the condition of vehicles without VDC and TCS control.

CAUTION:

If the Fail-Safe function is activated, then perform self-diagnosis for “ABS” with CONSULT.

JRFWC1194GB

ABS ACTUATOR AND ELECTRIC UNIT (CONTROL UNIT)

BRC-97

< ECU DIAGNOSIS INFORMATION >

[VDC/TCS/ABS]

C

D

E

G

H

I

J

K

L

M

A

B

BRC

N

O

P

ABS, EBD SYSTEM

If ABS malfunction electrically, ABS warning lamp, VDC warning lamp will turn ON. If EBD malfunction electri-
cally, brake warning lamp, ABS warning lamp, and VDC warning lamp will turn ON. Simultaneously, the VDC/
TCS/ABS become one of the following conditions of the fail safe function.
• For malfunction of ABS, only the EBD is activated and the condition of vehicle is the same condition of vehi-

cles without TCS/ABS system.
NOTE:
ABS self-diagnosis sound may be heard. That is a normal condition because a self-diagnosis for “Ignition
switch ON” and “The first starting” are being performed.

• For malfunction of EBD, EBD and ABS become inoperative, and the condition of vehicle is the same as the

condition of vehicles without TCS/ABS, EBD system.

DTC Inspection Priority Chart

INFOID:0000000009950028

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority
chart.

Priority

Detected items (DTC)

1

• U1000 CAN COMM CIRCUIT
• U1002 SYSTEM COMM

2

• C1110 CONTROLLER FAILURE
• C1153 EMERGENCY BRAKE
• C1170 VARIANT CORDING

3

• C1130 ENGINE SIGNAL 1
• C1144 ST ANG SEN SIGNAL

4

• C1109 BATTERY VOLTAGE [ABNORMAL]
• C1111 PUMP MOTOR
• C1140  ACTUATOR  RLY

5

• C1101 RR RH SENSOR-1
• C1102 RR LH SENSOR-1
• C1103 FR RH SENSOR-1
• C1104  FR  LH  SENSOR-1
• C1105 RR RH SENSOR-2
• C1106 RR LH SENSOR-2
• C1107 FR RH SENSOR-2
• C1108  FR  LH  SENSOR-2
• C1115 ABS SENSOR [ABNORMAL SIGNAL]
• C1116 STOP LAMP SW
• C1120 FR LH IN ABS SOL
• C1121 FR LH OUT ABS SOL
• C1122 FR RH IN ABS SOL
• C1123 FR RH OUT ABS SOL
• C1124 RR LH IN ABS SOL
• C1125 RR LH OUT ABS SOL
• C1126 RR RH IN ABS SOL
• C1127 RR RH OUT ABS SOL
• C1142 PRESS SEN CIRCUIT
• C1143 ST ANG SEN CIRCUIT
• C1145 YAW RATE SENSOR
• C1146 SIDE G-SEN CIRCUIT
• C1164  CV  1
• C1165  CV  2
• C1166  SV  1
• C1167  SV  2

6

• C1155 BR FLUID LEVEL LOW
