FRONT WASHER NOZZLE AND TUBE WW-145 < REMOVAL AND INSTALLATION > C D E F G H I J K M A B WW N O P 2. Disconnect front washer tube from front washer nozzle (1). 3. While pressing pawl (A) on the cowl top cover front side of front INSTALLATION Install in the reverse order of removal. CAUTION: The spray positions differ, check that left and right nozzles are installed correctly. Inspection and Adjustment INFOID:0000000009945879 INSPECTION Check valve Inspection Check that air can pass through the hose by blowing forward (toward ADJUSTMENT Washer Nozzle Spray Position Adjustment Adjust spray positions to match the positions shown in the figure. JPLIA0377ZZ JPLIA0685ZZ 1. Black printed frame line : Spray area : Target spray position JPLIA1762ZZ |
