ECU DIAGNOSIS INFORMATION

BCM

List of ECU Reference

INFOID:0000000009541086

ECU

Reference

BCM (with Intelligent Key system)

BCS-28, "Reference Value"

BCS-46, "Fail-safe"

BCS-47, "DTC Inspection Priority Chart"

BCS-48, "DTC Index"

BCM (without Intelligent Key system)

BCS-95, "Reference Value"

BCS-108, "Fail-safe"

BCS-109, "DTC Inspection Priority Chart"

BCS-109, "DTC Index"

DEF-12

< WIRING DIAGRAM >

REAR WINDOW DEFOGGER SYSTEM

WIRING DIAGRAM

REAR WINDOW DEFOGGER SYSTEM

Wiring Diagram

INFOID:0000000009541087

AALWA0651GB

REAR WINDOW DEFOGGER SYSTEM

DEF-13

< WIRING DIAGRAM >

C

D

E

F

G

H

I

J

K

M

A

B

DEF

N

O

P

AALIA1428GB

DEF-14

< WIRING DIAGRAM >

REAR WINDOW DEFOGGER SYSTEM

AALIA1429GB
