Nissan Versa Note. Manual - part 146

BRM-36

< REMOVAL AND INSTALLATION >

REPLACEMENT OPERATIONS

Rear Fender

INFOID:0000000009345090

AWKIA2544ZZ

Replacement parts

z

Rear Fender

Recommended sectioning location

Front

REPLACEMENT OPERATIONS

BRM-37

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Rear Panel

INFOID:0000000009345091

Replacement parts

z

Rear panel

A. Mig welds

Front

AWKIA2550ZZ

BRM-38

< REMOVAL AND INSTALLATION >

REPLACEMENT OPERATIONS

Rear Floor Rear

INFOID:0000000009345092

Work after rear panel assembly has been removed.

Replacement parts

z

Rear floor rear

AWKIA2545ZZ

REPLACEMENT OPERATIONS

BRM-39

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

BRM

N

O

P

Rear Side Member Extension

INFOID:0000000009345093

Work after rear panel assembly and rear floor rear have been removed.

Replacement parts

z

Rear side member extension

Front

AWKIA2551ZZ
