AV-152

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

AV CONTROL UNIT

6

(SB)

15

(G)

Steering switch signal A

Input

ON

Press SOURCE switch

 0V

Press

switch

1.0V

Press

switch

2.0V

Press

switch

3.0V

Except above

5.0V

7

(W)

Ground ACC power supply

Input

ACC

—

Battery voltage

8

(L)

—

CAN  (H)

Input/

Output

—

—

—

9

 (LG/R)

44

(B)

Illumination control signal

Input

ON

Headlamps ON

Battery voltage

11

(O)

12

(V)

Sound signal front speaker
RH

Output

ON

Sound output

13

(L)

14

(Y)

Sound signal rear speaker
RH

Output

ON

Sound output

16

(V)

15

(G)

Steering switch signal B

Input

ON

Press

switch

0V

Press

switch

1.0V

Press

switch

2.0V

Except above

5.0V

17

(P)

—

CAN  (L)

Input/

Output

—

—

—

18

(LG)

Ground Vehicle speed signal

Input

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

19

(Y)

Ground Battery power supply

Input

OFF

—

Battery voltage

20

(B/W)

Ground Ground

—

ON

—

0 V

23

(R)

—

MR output

Output

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

SKIB3609E

JSNIA0012GB

AV

AV CONTROL UNIT

AV-153

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

28

(Y)

Ground Reverse signal

Input

ON

Selector lever in R (re-
verse)

Battery voltage

Selector lever in any posi-
tion other than R (reverse)

0 V

30

(Y)

Ground AUX jack audio signal LH

Input

ON

Received audio signal
(AUX input)

31

(G)

Ground

AUX ground

—

ON

—

0V

32

(L)

Ground AUX jack audio signal RH

Input

ON

Received audio signal
(AUX input)

35

(Shield)

—

Camera image signal
shield

—

—

—

—

36

(G)

Ground Camera image signal

Input

ON

When camera image is dis-
played

37

(O)

Ground Ignition power supply

Input

ON

—

Battery voltage

42

(L)

—

MIC VCC

Input

ON

—

—

43

(P)

41

(Shield)

Microphone signal

Input

ON

While speaking into micro-
phone.

53

(W)

—

V BUS signal

—

—

—

—

54

(G)

—

USB ground

—

—

—

—

55

(L)

—

USB D+ signal

—

—

—

—

56

(R)

—

USB D

− signal

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

SKIB3609E

SKIB2251J

SKIB3609E

AV-154

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

AV CONTROL UNIT

DTC Index

INFOID:0000000009459997

57

(Shield)

—

USB shield

—

—

—

—

58

(B)

Ground Antenna amp. ON signal

Output

ON

AV control unit ON, FM-AM
selected.

Battery voltage

59

(B)

Ground AM-FM main antenna

Input

ON

AV control unit ON, FM-AM
selected.

5.0 V

61

(B)

Ground GPS antenna signal

Input

ON

AV control unit ON, NAV se-
lected.

5.0 V

62

(Shield)

—

GPS antenna shield

—

—

—

—

63

(B)

Ground Satellite antenna signal

Input

ON

AV control unit ON, XM se-
lected.

5.0 V

64

(Shield)

—

Satellite antenna shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

CONSULT Display

Reference Page

U1000: CAN COMM CIRCUIT

AV-187, "AV CONTROL UNIT : DTC Logic"

U1010: CONTROL UNIT (CAN)

AV-188, "AV CONTROL UNIT : DTC Logic"

U1200: Cont Unit

AV-197, "DTC Logic"

U1217: BLUETOOTH MODULE

AV-198, "DTC Logic"

U1229: iPod CERTIFICATION

AV-199, "DTC Logic"

U122F: Digital broadcasting connection error

AV-200, "DTC Logic"

U1244: GPS ANTENNA CONN

AV-202, "DTC Logic"

U1258: XM ANTENNA CONN

AV-203, "DTC Logic"

U1263: USB OVERCURRENT

AV-204, "DTC Logic"

U1264: ANTENNA AMP TERMINAL

AV-205, "DTC Logic"

U12AA: Configuration Error

AV-206, "DTC Logic"

U12AC: Display Temperature too High

AV-207, "DTC Logic"

U12AD: ECU Temperature too High

AV-208, "DTC Logic"

U12AE: Internal Amplifier temperature Warning

AV-209, "DTC Logic"

U12AF: CD Mechanism Temperature Warning

AV-210, "DTC Logic"

U12B0: Supply Voltage Goes below 9V > 20s

AV-211, "DTC Logic"

U12B1: Supply Voltage Goes High > 16V for 20s

AV-212, "DTC Logic"

AV

AROUND VIEW MONITOR CONTROL UNIT

AV-155

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

AROUND VIEW MONITOR CONTROL UNIT

Reference Value

INFOID:0000000009681919

VALUES ON THE DIAGNOSIS TOOL

TERMINAL LAYOUT

PHYSICAL VALUES

Monitor Item

Condition

Value/Status

CAMERA OFF SIGNAL

CAMERA switch ON.

Off

CAMERA switch OFF.

On

CAMERA SWITCH SIGNAL

CAMERA switch OFF.

Off

CAMERA switch ON.

On

DR-SIDE CAMERA IMAGE SIG

Side camera LH inoperative.

NG

Side camera LH operative.

OK

F-CAMERA IMAGE SIG

Front camera inoperative.

NG

Front camera operative.

OK

PA-SIDE CAMERA IMAGE SIG

Side camera RH inoperative.

NG

Side camera RH operative.

OK

REAR CAMERA IMAGE SIGNAL

Rear camera LH inoperative.

NG

Rear camera LH operative.

OK

REVERSE SIGNAL

When selector lever is in any position other than R (reverse).

Off

When selector lever in R (reverse).

On

ST ANGLE SENSOR SIGNAL

Around view monitor control unit is not receiving steering angle
sensor signal.

Off

Around view monitor control unit is receiving steering angle sen-
sor signal.

On

ST ANGLE SENSOR TYPE

Steering angle sensor type.

Absolute

ST GEAR RATIO TYPE

Steering gear ratio type.

Type O

STEERING POSITION

Left hand drive vehicle.

LHD

Right hand drive vehicle.

RHD

VEHICLE SPEED SIGNAL

While driving, equivalent to speedometer reading

mph, km/h

AWNIA3139ZZ

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

1

(B)

Ground Ground

—

ON

—

0 V

2

(Y/G)

Ground Battery power supply

Input

OFF

—

Battery voltage
