AV-36

< DTC/CIRCUIT DIAGNOSIS >

[BASE AUDIO]

POWER SUPPLY AND GROUND CIRCUIT

1.

CHECK FUSE

Check that the following fuses are not blown.

Are the fuses blown?

YES

>> Replace the blown fuse after repairing the affected circuit.

NO

>> GO TO 2.

2.

CHECK POWER SUPPLY CIRCUIT

1. Turn ignition switch OFF.
2. Disconnect Bluetooth

®

 control unit connector B33.

3. Check voltage between Bluetooth

®

 control unit connector B33 and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace harness or connectors.

3.

CHECK GROUND CIRCUIT

1. Turn ignition switch OFF.
2. Check continuity between Bluetooth

®

 control unit connector B33 and ground.

Is the inspection result normal?

YES

>> Inspection End.

NO

>> Repair or replace harness or connectors.

Terminal No.

Signal name

Fuse No.

1

Battery power supply

29 (15A)

2

ACC power supply

17 (10A)

3

Ignition signal

5 (10A)

Bluetooth

®

 control unit

Ground

Condition

Voltage

(Approx.)

Connector

Terminal

B33

1

—

Ignition switch: OFF

Battery voltage

2

Ignition switch: ACC

3

Ignition switch: ON

Bluetooth

®

 control unit

Ground

Continuity

Connector

Terminal

B33

4

—

Yes

21

22

24

27

AV

FRONT DOOR SPEAKER

AV-37

< DTC/CIRCUIT DIAGNOSIS >

[BASE AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

FRONT DOOR SPEAKER

Diagnosis Procedure

INFOID:0000000009681845

Regarding Wiring Diagram information, refer to

AV-23, "Wiring Diagram"

.

1.

CONNECTOR CHECK

Check the audio unit and speaker connectors for the following:

•  Proper connection

•  Damage

•  Disconnected or loose terminals
Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair the terminals or connectors.

2.

CHECK FRONT DOOR SPEAKER SIGNAL CIRCUIT CONTINUITY

1. Disconnect audio unit connector M43 and suspect front door speaker connector.

2. Check continuity between audio unit connector M43 and suspect front door speaker connector.

3. Check continuity between audio unit connector M43 and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace harness or connectors.

3.

CHECK FRONT DOOR SPEAKER SIGNAL

1. Connect audio unit connector M43 and suspect front door speaker connector.

2. Turn ignition switch to ACC.

3. Push audio unit POWER switch.

4. Check signal between the terminals of audio unit connector M43.

Audio unit

Front door speaker

Continuity

Connector

Terminal

Connector

Terminal

M43

2

D12 (LH)

1

Yes

3

2

11

D112 (RH)

1

12

2

Audio unit

Ground

Continuity

Connector

Terminal

M43

2

—

No

3

11

12

Audio unit connector M43

Condition

Reference value

(+)

(

−)

Terminal

Terminal

AV-38

< DTC/CIRCUIT DIAGNOSIS >

[BASE AUDIO]

FRONT DOOR SPEAKER

Is the inspection result normal?

YES

>> Replace front door speaker. Refer to

AV-54, "Removal and Installation"

.

NO

>> Replace audio unit. Refer to

AV-53, "Removal and Installation"

.

2

3

Audio signal output

11

12

SKIB3609E

AV

REAR DOOR SPEAKER

AV-39

< DTC/CIRCUIT DIAGNOSIS >

[BASE AUDIO]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

REAR DOOR SPEAKER

Diagnosis Procedure

INFOID:0000000009681846

Regarding Wiring Diagram information, refer to

AV-23, "Wiring Diagram"

.

1.

CONNECTOR CHECK

Check the audio unit and speaker connectors for the following:

•  Proper connection

•  Damage

•  Disconnected or loose terminals
Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair the terminals or connectors.

2.

CHECK REAR SPEAKER SIGNAL CIRCUIT CONTINUITY

1. Disconnect audio unit connector M43 and suspect rear door speaker connector.

2. Check continuity between audio unit connector M43 and suspect rear door speaker connector.

3. Check continuity between audio unit connector M43 and ground.

Is the inspection result normal?

YES

>> GO TO 3.

NO

>> Repair or replace harness or connectors.

3.

CHECK REAR SPEAKER SIGNAL

1. Connect audio unit connector M43 and suspect rear door speaker connector.

2. Turn ignition switch to ACC.

3. Push audio unit POWER switch.

4. Check signal between the terminals of audio unit connector M43.

Audio unit

Rear door speaker

Continuity

Connector

Terminal

Connector

Terminal

M43

4

D207 (LH)

1

Yes

5

2

13

D307 (RH)

1

14

2

Audio unit

Ground

Continuity

Connector

Terminal

M43

4

—

No

5

13

14

Audio unit connector M43

Condition

Reference value

(+)

(

−)

Terminal

Terminal
