Nissan Rogue. Manual - part 996





PWC-66

< REMOVAL AND INSTALLATION >

POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH

POWER WINDOW AND DOOR LOCK/UNLOCK SWITCH RH

Removal and Installation

INFOID:0000000011278745

REMOVAL

1. Remove the front door pull handle bracket (RH). Refer to

INT-15, "Exploded View"

.

2. Release pawls using a suitable tool (A) and remove front door

power window and door lock/unlock switch finisher (RH) (1).

: Pawl

3. Disconnect the harness connector from the front door power window and door lock/unlock switch (RH).
4. Release pawls, then separate front power window and door

lock/unlock switch (RH) (1) from switch finisher (2).

: Pawl

INSTALLATION

Installation is in the reverse order of removal.

NOTE:

When the front power window and door lock/unlock switch (RH) is removed or replaced, it is necessary to per-

form the initialization procedure. Refer to

PWC-28, "ADDITIONAL SERVICE WHEN REMOVING BATTERY

NEGATIVE TERMINAL : Description"

.

ALKIA3472ZZ

ALKIA3473ZZ

REAR POWER WINDOW SWITCH

PWC-67

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

J

L

M

A

B

PWC

N

O

P

REAR POWER WINDOW SWITCH

Removal and Installation

INFOID:0000000011278746

REMOVAL

1. Remove screw cover (1).

2. Remove screw (A).

3. Release pawls using a suitable tool (A) and remove rear power

window switch finisher (1).

: Pawl

4. Disconnect harness connector from rear power window switch.
5. Release the pawls, then separate the rear power window switch

(1) from the switch finisher (2).

: Pawl

INSTALLATION

Installation is in the reverse order of removal.

ALJIA1377ZZ

ALJIA1378ZZ

ALJIA1344ZZ

ALKIA3475ZZ

PWO-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000011278432

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. Information necessary to service the system safely is included in the SR and SB section of

this Service Manual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery and wait at least three minutes before performing any service.
