Nissan Rogue. Manual - part 920

MWI

COMBINATION METER

MWI-27

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

*: DDS (hill descent control)

NOTE:

Some items are not available according to vehicle specification.

TERMINAL LAYOUT

PHYSICAL VALUES

STRG SW INPUT

Ignition switch ON

BACK switch is pressed.

SW1

MENU UP switch is pressed.

SW2

MENU DOWN switch is pressed.

SW3

Voice recognition switch is pressed.

SW4

MENU OK switch is pressed.

SW5

VOL DOWN switch is pressed.

SW6

VOL UP switch is pressed.

SW7

TEL switch is pressed.

SW8

Display back switch is pressed.

SW9

Display next switch is pressed.

SW10

Other than above.

NO INPUT

BSW IND

Ignition switch ON

Blind spot warning lamp ON.

On

Blind spot warning lamp OFF.

Off

BSW W/L

Ignition switch ON

Blind spot warning displayed.

On

Other than above.

Off

Monitor Item

Condition

Value/Status

JSNIA6097ZZ

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

–

Signal name

Input/

Out-

put

1

(B)

Ground

Ground

—

—

—

0 V

7

(BG)

Ground Security signal

Input

Ignition
switch
OFF

Security indicator ON.

0 V

Security indicator OFF.

Battery voltage

9

(GR)

Ground ECO mode switch

—

—

—

—

10

(P)

Ground O/D OFF switch

—

—

—

—

MWI-28

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

15

(L)

Ground

Ambient sensor signal

Input

Ignition
switch
ON

—

17

(BG)

Ground

Meter control switch
ground

—

—

—

0  V

18

(SB)

Ground Trip/reset signal

Input

Ignition
switch
OFF or
ON

Trip/Reset switch is pressed.

0 V

Other than the above.

5.0 V

20

(Y)

Ground

Ambient sensor ground

—

—

—

0 V

21

(L)

Ground

Steering switch ground

—

—

—

0 V

22

(Y)

Ground

Steering switch output 1

—

—

—

—

23

(GR)

Ground

Steering switch output 2

—

—

—

—

24

(BR)

Ground

Washer fluid level
switch signal

Input

Ignition
switch
ON

Washer fluid level switch ON.

0 V

Washer fluid level switch OFF.

Battery voltage

25

(V)

Ground

Brake fluid level switch
signal

Input

Ignition
switch
ON

Brake fluid level low.

0 V

Brake fluid level normal.

Battery voltage

26

(G)

Ground

Parking brake switch
signal

Input

Ignition
switch
ON

Parking brake applied.

0 V

Parking brake released.

Battery voltage

28

(Y)

Ground

Seat belt buckle switch
signal LH

Input

Ignition
switch
ON

When driver seat belt is fastened.

Battery voltage

When driver seat belt is unfas-
tened.

0 V

29

(R)

Ground

Sport mode switch sig-
nal

—

—

—

—

36

(GR)

Ground

Illumination control
switch signal (+)

Input

Ignition
switch
OFF or
ON

When illumination control switch
(+) is pressed.

0 V

Other than the above.

5.0 V

37

(V)

Ground

Illumination control
switch signal (-)

Input

Ignition
switch
OFF or
ON

When illumination control switch
(-) is pressed.

0 V

Other than the above.

5.0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

–

Signal name

Input/

Out-

put

JSNIA0014GB

MWI

COMBINATION METER

MWI-29

< ECU DIAGNOSIS INFORMATION >

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

38

(G)

Ground

Vehicle speed signal
(8-pulse)

Out-
put

Ignition
switch
ON

Speedometer operated [When
vehicle speed is approx. 25 MPH
(40 km/h)].

NOTE:
The maximum voltage varies de-
pending on the specification (desti-
nation unit).

39

(W)

Ground

Vehicle speed signal
(2-pulse)

Out-

put

Ignition
switch
ON

Speedometer operated
[When vehicle speed is approx.
25 MPH (40 km/h)].

NOTE:
The maximum voltage varies de-
pending on the specification (desti-
nation unit).

41

(L)

Ground CAN high

—

—

—

—

42

(P)

Ground CAN low

—

—

—

—

43

(W)

Ground

Illumination control sig-
nal

Out-
put

Ignition
switch
ON

• Lighting switch 1st position
• When meter illumination is

minimum.

• Lighting switch 1st position
• When meter illumination is step

11.

• Lighting switch 1st position
• When meter illumination is

maximum.

0 V

44

(LA/

B)

Ground

Fuel level sensor
ground

—

Ignition
switch
ON

—

0  V

45

(LA/

G)

Ground

Battery power supply

—

—

—

Battery voltage

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

–

Signal name

Input/

Out-

put

JSNIA0012GB

JSNIA0015GB

JSNIA5983GB

JPNIA1686GB

MWI-30

< ECU DIAGNOSIS INFORMATION >

COMBINATION METER

Fail-safe

INFOID:0000000011279790

The combination meter activates the fail-safe control if the CAN communication lines between each unit are

malfunctioning.

46

(LA/

BR)

Ground

Ignition signal

—

Ignition
switch
ON or
START

—

Battery voltage

47

(SB)

Ground M CAN high

—

—

—

—

48

(LG)

Ground M CAN low

—

—

—

—

51

(LA/

L)

Ground Fuel level sensor signal

—

Ignition
switch
ON

Fuel gauge indication position.

Battery voltage

52

(B)

Ground

Ground

—

—

—

0 V

Terminal No.

(Wire color)

Description

Condition

Value

(Approx.)

+

–

Signal name

Input/

Out-

put

Function

Specifications

Speedometer

Reset to zero by suspending communication.

Tachometer

Engine coolant temperature gauge

Meter illumination control

When suspending communication, changes to nighttime mode.

Buzzer

Turns OFF by suspending communication.

Information display

Current fuel consumption

The last result calculated during normal condition is indicated.

Average fuel consumption

Average vehicle speed

Range (Distance to empty)

Driving distance

Door open warning

The display turns OFF by suspending communication.

Lift gate open warning

Low tire pressure warning

Parking brake release warning

Fuel filler cap warning

Oil pressure warning

CVT warning

BSW/LDW warning

Odo/trip meter

An indicated value is maintained at communications blackout.

Shift position indicator

The indicator turns OFF by suspending communication.
