Nissan Rogue. Manual - part 897





PRECAUTIONS

MA-3

< PRECAUTION >

C

D

E

F

G

H

I

J

K

L

M

B

MA

N

O

A

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000011277758

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. Information necessary to service the system safely is included in the SR and SB section of

this Service Manual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery and wait at least three minutes before performing any service.

MA-4

< PREPARATION >

PREPARATION

PREPARATION

PREPARATION

Special Service Tool

INFOID:0000000011277759

The actual shape of the tools may differ from those illustrated here.

Commercial Service Tool

INFOID:0000000011277760

Tool number
(TechMate No.)
Tool name

Description

KV991J0070
(J-45695-A)
Coolant refill tool

Refilling engine cooling system

 (J-48891)
14 mm spark plug socket

Removing and installing spark plug

LMA053

AWBIA1785ZZ

Tool name

Description

Power tool

Loosening nuts, screws and bolts

Oil filter wrench assortment

Removing oil filter

PIIB1407E

AWBIA1656ZZ

GENERAL MAINTENANCE

MA-5

< PERIODIC MAINTENANCE >

C

D

E

F

G

H

I

J

K

L

M

B

MA

N

O

A

PERIODIC MAINTENANCE

GENERAL MAINTENANCE

Explanation of General Maintenance

INFOID:0000000011277761

General maintenance includes those items which should be checked during the normal day-to-day operation

of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the

checks and inspections themselves or have their NISSAN dealers do them.

OUTSIDE THE VEHICLE

The maintenance items listed here should be performed from time to time, unless otherwise specified.

INSIDE THE VEHICLE

The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,

etc.

Item

Reference page

Tires

Check the pressure with a gauge often and always prior to long distance trips. Ad-
just the pressure in all tires, including the spare, to the pressure specified. Check
carefully for damage, cuts or excessive wear.

WT-73

Wheel nuts

When checking the tires, make sure no nuts are missing, and check for any loose
nuts. Tighten if necessary.

Tire rotation

Tires should be rotated every 5,000 miles (8,000 km). If the vehicle is equipped with
different sized tires in the front and rear, tires cannot be rotated.

WT-64

Tire Pressure Monitoring
System (TPMS) transmitter
components

Replace the TPMS transmitter grommet seal, valve core and cap when the tires are
replaced due to wear or age.

WT-68

Wheel alignment and bal-
ance

If the vehicle should pull to either side while driving on a straight and level road, or
if you detect uneven or abnormal tire wear, there may be a need for wheel align-
ment. If the steering wheel or seat vibrates at normal highway speeds, wheel bal-
ancing may be needed. For additional information regarding tires, refer to
“lmportant Tire Safety Information” (US) or “Tire Safety Information” (Canada) in the
NISSAN Warranty Information Booklet.

FSU-7

RSU-6
WT-64

Windshield

Clean the windshield on a regular basis. Check the windshield at least every six
months for cracks or other damage. Repair as necessary.

Windshield wiper blades

Check for cracks or wear if they do not wipe properly.

Doors and engine hood

Check that all doors and the engine hood operate smoothly as well as the back
door. Also make sure that all latches lock securely. Lubricate if necessary. Make
sure that the secondary latch keeps the hood from opening when the primary latch
is released.
When driving in areas using road salt or other corrosive materials, check lubrication
frequently.

MA-39

Lamps

Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and other
lamps are all operating properly and installed securely. Also check headlamp aim.
Clean the headlamps on a regular basis.

Item

Reference page

Warning lamps and
chimes

Make sure that all warning lamps and chimes are operating properly.

Windshield wiper and
washer

Check that the wipers and washer operate properly and that the wipers do not streak.

Windshield defroster

Check that the air comes out of the defroster outlets properly and in sufficient quantity
when operating the heater or air conditioner.

Steering wheel

Check that it has the specified play. Check for changes in the steering condition, such
as excessive play, hard steering or strange noises.
 Free play: Less than 35 mm (1.38 in)

MA-6

< PERIODIC MAINTENANCE >

GENERAL MAINTENANCE

UNDER THE HOOD AND VEHICLE

The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).

Seats

Check seat position controls such as seat adjusters, seatback recliner, etc. to make
sure they operate smoothly and that all latches lock securely in every position. Check
that the head restrains move up and down smoothly and that the locks (if equipped)
hold securely in all latched positions. Check that the latches lock securely for folding-
down rear seatbacks.

Seat belts

Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and re-
tractors) operate properly and smoothly and are installed securely. Check the belt
webbing for cuts, fraying, wear or damage.

MA-40

Accelerator pedal

Check the pedal for smooth operation and make sure the pedal does not catch or
require uneven effort. Keep the floor mats away from the pedal.

Brakes

Check that the brake does not pull the vehicle to one side when applied.

Brake pedal and booster

Check the pedal for smooth operation and make sure it has the proper distance un-
der it when depressed fully. Check the brake booster function. Be sure to keep the
floor mats away from the pedal.

BR-15
BR-10

Parking brake

Check that the lever or the pedal has the proper travel and make sure that the vehicle
is held securely on a fairly steep hill when only the parking brake is applied.

PB-4

CVT P (Park) position
mechanism

On a fairly steep hill check that the vehicle is held securely with the selector lever in
the P (Park) position without applying any brakes.

Item

Reference page

Item

Reference page

Windshield washer fluid

Check that there is adequate fluid in the tank.

Engine coolant level

Check the coolant level when the engine is cold.

CO-8

Radiator and hoses

Check the front of the radiator and clean off any dirt, insects, leaves, etc., that may
have accumulated. Make sure the hoses have no cracks, deformation, deterioration
or loose connections.

CO-12

Brake fluid level

Make sure that the brake fluid level is between the “MAX” and “MIN” lines on the
reservoir.

BR-8

Battery

Check the fluid level in each cell. It should be between the “MAX” and “MIN” lines.
Vehicles operated in high temperatures or under severe conditions require frequent
checks of the battery fluid level.

PG-69

Engine drive belts

Make sure that no belt is frayed, worn, cracked or oily.

EM-15

Engine oil level

Check the level on the oil level gauge after parking the vehicle on a level spot and
turning off the engine.

LU-7

Exhaust system

Make sure there are no loose supports, cracks or holes. If the sound of the exhaust
seems unusual or there is a smell of exhaust fumes, immediately locate the trouble
and correct it.

EX-4

Underbody

The underbody is frequently exposed to corrosive substances such as those used
on icy roads or to control dust. It is very important to remove these substances, oth-
erwise rust will form on the floor pan, frame, fuel lines and around the exhaust sys-
tem. At the end of winter, the underbody should be thoroughly flushed with plain
water, being careful to clean those areas where mud and dirt can easily accumulate.

Fluid leaks

Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle has
been parked for a while. Water dripping from the air conditioner after use is normal.
If you should notice any leaks or gasoline fumes are evident, check for the cause
and correct it immediately.
