ENGINE OIL

LU-9

< PERIODIC MAINTENANCE >

C

D

E

F

G

H

I

J

K

L

M

A

LU

N

P

O

Be sure to clean drain plug and install with new drain plug washer.

2. Refill with new engine oil.

Engine oil specification and viscosity: Refer to

MA-11, "Engine Oil Recommendation"

.

CAUTION:

• The refill capacity depends on the engine oil temperature and drain time. Use these specifica-

tions for reference only.

• Always use oil level gauge to determine the proper amount of engine oil in engine.

3. Warm up the engine and check area around drain plug and oil filter for engine oil leaks.
4. Stop the engine and wait for 5 minutes.
5. Check the engine oil level. Refer to

LU-7, "Inspection"

.

Tightening torque : Refer to

EM-36, "Exploded View"

.

Engine oil capacity

: Refer to

LU-18, "Oil Capacity"

.

LU-10

< PERIODIC MAINTENANCE >

OIL FILTER

OIL FILTER

Removal and Installation

INFOID:0000000011277146

REMOVAL

1. Remove fender protector side cover (RH). Refer to

EXT-28, "FENDER PROTECTOR : Exploded View"

.

2. Drain engine oil. Refer to

LU-8, "Draining"

.

3. Remove oil filter using suitable tool (A)..

WARNING:

Be careful not to burn yourself, as engine oil may be hot.

CAUTION:

• When removing, prepare a shop cloth to absorb any

engine oil leaks or spills.

• Do allow engine oil to adhere to drive belt.

• Completely wipe off any engine oil that adheres to engine

and vehicle.

• Oil filter is provided with relief valve. Use genuine NISSAN

oil filter or equivalent.

INSTALLATION

1. Remove foreign materials adhering to oil filter installation surface.
2. Apply new engine oil to the oil seal contact surface of new oil fil-

ter.

3. Screw oil filter manually until it touches the installation surface,

then tighten it by 2/3 turn (A). Or tighten to the specification.

: Front

JPBIA0890ZZ

ALC094

SMA010

Oil filter:

 : 17.7 N·m (1.8 kg-m, 13 ft-lb)

JPBIA0077ZZ

OIL FILTER

LU-11

< PERIODIC MAINTENANCE >

C

D

E

F

G

H

I

J

K

L

M

A

LU

N

P

O

Inspection

INFOID:0000000011277147

INSPECTION AFTER INSTALLATION

1. Check the engine oil level. Refer to

LU-7, "Inspection"

.

2. Start the engine, and check that there is are no leaks of engine oil.
3. Stop the engine and wait for at least 5 minutes.
4. Check the engine oil level, and adjust the level (if necessary). Refer to

LU-7, "Inspection"

.

LU-12

< REMOVAL AND INSTALLATION >

OIL COOLER

REMOVAL AND INSTALLATION

OIL COOLER

Exploded View

INFOID:0000000011277148

Removal and Installation

INFOID:0000000011277149

WARNING:

Be careful not to burn yourself, as engine oil and engine coolant may be hot.

NOTE:

When removing components such as hoses, tubes/lines, etc., cap or plug openings to prevent fluid from spill-

ing.

REMOVAL

1. Drain engine coolant. Refer to

CO-8, "Draining"

.

2. Remove front air spoiler (RH). Refer to

EXT-16, "Exploded View"

.

3. Remove fender protector (RH). Refer to

EXT-28, "FENDER PROTECTOR : Exploded View"

.

4. Disconnect water hoses from the oil cooler.

1.

Intake manifold

2.  Cylinder block

3.

Clamp

4.

Water hose

5.

Water hose clip

6.

Water hose

7.

Oil cooler

8.

Gasket

9.

Oil cooler relief valve

Front

A. Refer to INSTALLATION

AWBIA2283ZZ
