HAC-26 < SYSTEM DESCRIPTION > [AUTOMATIC AIR CONDITIONING] DIAGNOSIS SYSTEM (IPDM E/R) DIAGNOSIS SYSTEM (IPDM E/R) CONSULT Function (IPDM E/R) INFOID:0000000011379868 APPLICATION ITEM CONSULT performs the following functions via CAN communication with IPDM E/R. ECU IDENTIFICATION The IPDM E/R part number is displayed. SELF DIAGNOSTIC RESULT DATA MONITOR Direct Diagnostic Mode Description ECU Identification The IPDM E/R part number is displayed. Self Diagnostic Result The IPDM E/R self diagnostic results are displayed. Data Monitor The IPDM E/R input/output data is displayed in real time. Active Test The IPDM E/R activates outputs to test components. CAN Diag Support Mntr The result of transmit/receive diagnosis of CAN communication is displayed. Monitor Item [Unit] Description REVERSE SIGNAL [Open/Close] Indicates condition of transmission range switch R (Reverse) po- IGN RELAY [Open/Close] Indicates condition of ignition relay-1. PUSH SW [Open/Close] Indicates condition of push-button ignition switch. INTERLOCK/PNP SW [Open/Close] Indicates condition of transmission range switch P (Park) and N OIL PRESSURE SW [Open/Close] Indicates condition of oil pressure switch. HOOD SW [Open/Close] Indicates condition of hood switch. COMPRESSOR [OFF/ON] Indicates condition of A/C compressor. HORN RELAY [OFF/ ON] Indicates condition of horn relay. COOLING FAN [OFF/ON] Indicates condition of cooling fan relay-1. FRONT WIPER HI/LO RELAY [OFF/ON] Indicates condition of front wiper high relay. FRONT WIPER RELAY [OFF/ON] Indicates condition of front wiper relay. IGN RELAY OFF STATUS [OFF/ON] Indicates condition of ignition relay-1 OFF status. IGN RELAY ON STATUS [OFF/ON] Indicates condition of ignition relay-1 ON status. COOLING FAN RELAY 1 [OFF/ON] Indicates condition of cooling fan relay-1. STARTER RELAY [OFF/ON] Indicates condition of starter relay. COMP ECV DUTY [%] Indicates condition of A/C compressor. COOLING FAN RELAY 2 [%] Indicates condition of cooling fan relay-2. FR FOG LAMP LH [%] Indicates condition of front fog lamp LH. FR FOG LAMP RH [%] Indicates condition of front fog lamp RH. PARKING LAMP [%] Indicates condition of parking lamp. TAIL LAMP LH [%] Indicates condition of tail lamp LH. TAIL LAMP RH [%] Indicates condition of tail lamp RH. DAYTIME RUNNING LIGHT LH [%] Indicates condition of daytime running light LH. DAYTIME RUNNING LIGHT RH [%] Indicates condition of daytime running light RH. HEADLAMP (HI) LH [%] Indicates condition of headlamp high beam LH. |
