DIAGNOSIS SYSTEM (IPDM E/R)
SEC-131
< SYSTEM DESCRIPTION >
[WITHOUT INTELLIGENT KEY SYSTEM]
C
D
E
F
G
H
I
J
L
M
A
B
SEC
N
O
P
ACTIVE TEST
CAN DIAG SUPPORT MNTR
LAN-14, "CAN Diagnostic Support Monitor"
.
TURN SIGNAL REQ [Off/LH/RH]
Indicates condition of turn signal request.
FR WIPER REQ [RETURN/LOW/HIGH]
Indicates condition of front wiper motor request.
SHIFT POSITION [P/R/N/D/L]
Indicates condition of transmission range switch positions.
LOW BEAM REQ [Off/On]
Indicates condition of headlamp low beam request.
POSITION LIGHT REQ [Off/On]
Indicates condition of parking lamp request.
COMPRESSOR REQ2 [Off/On]
Indicates condition of A/C compressor request.
IGNITION SW [Off/On]
Indicates condition of ignition switch.
VEHICLE SPEED (METER) [mph/km/h]
Indicates vehicle speed.
BAT DISCHARGE COUNT [0-100]
Indicates condition of battery discharge.
BATTERY STATUS [NG/OK]
Indicates battery status.
Monitor Item [Unit]
Description
Test item
Description
HORN
This test is able to check horn operation [Off/On].
FRONT WIPER
This test is able to check wiper motor operation [Off/Low/High].
COMPRESSOR
This test is able to check A/C compressor operation [Off/On].
COOLING FAN (DUAL)
This test is able to check cooling fan operation [Off/LO/HI].
HEADLAMP (HI)
This test is able to check headlamp high beam operation [Off/3/5].
HEADLAMP (LO)
This test is able to check headlamp low beam operation [Off/3/5].
FRONT FOG LAMP
This test is able to check front fog lamp operation [Off/3/5].
DAYTIME RUNNING LAMP
This test is able to check daytime running lamp operation [Off/3/5].
PARKING LAMP
This test is able to check parking lamp operation [Off/3/5].
TAIL LAMP
This test is able to check tail lamp operation [Off/3/5].
2015 Rogue NAM
