AV-244

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

BOSE SPEAKER AMP

8

 (G)

13

(R)

Front door speaker signal
RH

Output

ON

Sound output

9

(Y)

14

(BR)

Sound signal subwoofer

Output

ON

Sound output

11

(W)

Ground Battery power supply

Input

–

–

Battery voltage

12

(B)

Ground Ground

–

ON

–

0V

15

(V)

28

(BG)

Center speaker signal

Output

ON

Sound output

18

 (R)

32

(G)

Sound signal front LH

Input

ON

Sound output

19

 (Y)

20

(L)

Sound signal front RH

Input

ON

Sound output

21

 (V)

22

 (LG)

Sound signal rear LH

Input

ON

Sound output

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIA0177E

SKIB3609E

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E

AV

BOSE SPEAKER AMP

AV-245

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

23

 (W)

33

 (R)

Sound signal rear RH

Input

ON

Sound output

25

(G)

Ground

Subwoofer ON signal

Output

ON

–

Greater than 6.5V

31

(BR)

Ground

Amp. ON signal

Input

ON

–

Greater than 6.5V

37

 (G)

27

 (R)

Front tweeter signal RH

Output

ON

Sound output

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIA0177E

SKIA0177E

AV-246

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

AROUND VIEW MONITOR CONTROL UNIT

AROUND VIEW MONITOR CONTROL UNIT

WITHOUT DRIVER ASSISTANCE SYSTEM
WITHOUT DRIVER ASSISTANCE SYSTEM : Reference Value

INFOID:0000000011276933

VALUES ON THE DIAGNOSIS TOOL

TERMINAL LAYOUT

PHYSICAL VALUES

Monitor Item

Condition

Value/Status

CAMERA OFF SIGNAL

CAMERA switch ON.

Off

CAMERA switch OFF.

On

CAMERA SWITCH SIGNAL

CAMERA switch OFF.

Off

CAMERA switch ON.

On

DR-SIDE CAMERA IMAGE SIG

Side camera LH inoperative.

NG

Side camera LH operative.

OK

F-CAMERA IMAGE SIG

Front camera inoperative.

NG

Front camera operative.

OK

PA-SIDE CAMERA IMAGE SIG

Side camera RH inoperative.

NG

Side camera RH operative.

OK

REAR CAMERA IMAGE SIGNAL

Rear camera LH inoperative.

NG

Rear camera LH operative.

OK

REVERSE SIGNAL

When selector lever is in any position other than R (reverse).

Off

When selector lever in R (reverse).

On

ST ANGLE SENSOR SIGNAL

Around view monitor control unit is not receiving steering angle
sensor signal.

Off

Around view monitor control unit is receiving steering angle sen-
sor signal.

On

ST ANGLE SENSOR TYPE

Steering angle sensor type.

Absolute

ST GEAR RATIO TYPE

Steering gear ratio type.

Type O

STEERING POSITION

Left hand drive vehicle.

LHD

Right hand drive vehicle.

RHD

VEHICLE SPEED SIGNAL

While driving, equivalent to speedometer reading

mph, km/h

AWNIA3139ZZ

AV

AROUND VIEW MONITOR CONTROL UNIT

AV-247

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

1

(B)

Ground Ground

—

ON

—

0 V

2

(Y)

Ground Battery power supply

Input

OFF

—

Battery voltage

4

(SB)

Ground Ignition signal

Input

ON

—

Battery voltage

10

(R)

—

CAN  (L)

Input/

Output

— —

—

12

(L)

—

CAN  (H)

Input/

Output

— —

—

23

(Shield)

—

Camera image signal
shield

—

—

—

—

24

(G)

Ground Camera image signal

Output

ON

When camera image dis-
play

25

(B)

Ground Rear camera ground

—

ON

—

0 V

26

(R)

Ground Rear camera power supply

Output

ON

CAMERA selected
or
Shift selector in R (reverse)
position.

6.0 V

28

(W)

27

(Shield)

Rear camera image signal

Input

ON

CAMERA selected
or
Shift selector in R (reverse)
position.

29

(Y)

Ground Side camera LH ground

—

ON

—

0 V

30

(L)

Ground

Side camera LH power
supply

Output

ON

CAMERA selected
or
Shift selector in R (reverse)
position.

6.0 V

32

(G)

31

(Shield)

Side camera LH image sig-
nal

Input

ON

CAMERA selected
or
Shift selector in R (reverse)
position.

33

(L)

Ground Side camera RH ground

—

ON

—

0 V
