AV-240

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

AV CONTROL UNIT

8

(L)

—

CAN  (H)

Input/

Output

—

—

—

9

 (V)

Ground Illumination control signal

Input

ON

Headlamps ON

Battery voltage

10

(B)

—

Pre-amp sound signal
shield

—

—

—

—

11

(R)

12

(W)

Pre-amp sound signal front
RH

Output

ON

Sound output

13

(L)

14

(Y)

Pre-amp sound signal rear
RH

Output

ON

Sound output

17

(R)

—

CAN  (L)

Input/

Output

—

—

—

18

(G)

Ground Vehicle speed signal

Input

ON

When vehicle speed is ap-
prox. 40 km/h (25 MPH)

19

(L)

Ground Battery power supply

Input

OFF

—

Battery voltage

20

(B)

Ground Ground

—

ON

—

0 V

21

(G)

Ground AUX jack audio signal RH

Input

ON

Received audio signal
(AUX input)

22

(Y)

Ground

AUX ground

—

ON

—

0V

23

(L)

Ground AUX jack audio signal LH

Input

ON

Received audio signal
(AUX input)

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

SKIB3609E

JSNIA0012GB

SKIB3609E

SKIB3609E

AV

AV CONTROL UNIT

AV-241

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

25

(BR)

Ground Reverse signal

Input

ON

Selector lever in R (re-
verse)

Battery voltage

Selector lever in any posi-
tion other than R (reverse)

0 V

30

(BG)

—

MR output

Output

—

—

—

31

(SB)

—

AV communication (H)

Input/

Output

—

—

—

32

(LG)

—

AV communication (L)

Input/

Output

—

—

—

34

(W)

36

(Shield)

Microphone signal

Input

ON

While speaking into micro-
phone.

35

(B)

—

MIC VCC

Input

ON

—

—

37

(Shield)

—

AUX signal shield

—

—

—

—

38

(SB)

—

AV communication (H)

Input/

Output

—

—

—

39

(LG)

—

AV communication (L)

Input/

Output

—

—

—

40

(LG)

Ground Ignition power supply

Input

ON

—

Battery voltage

41

(W)

Ground Camera image signal

Input

ON

When camera image is dis-
played

42

(Shield)

—

Camera image signal
shield

—

—

—

—

45

(R)

—

V BUS signal

—

—

—

—

46

(W)

—

USB D

− signal

—

—

—

—

47

(G)

—

USB + signal

—

—

—

—

49

(B)

—

USB ground

—

—

—

—

50

(Shield)

—

USB shield

—

—

—

—

51

(B)

Ground Antenna amp. ON signal

Output

ON

AV control unit ON, FM-AM
selected.

Battery voltage

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

SKIB3609E

SKIB2251J

AV-242

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

AV CONTROL UNIT

DTC Index

INFOID:0000000011276931

52

(B)

Ground AM-FM main antenna

Input

ON

AV control unit ON, FM-AM
selected.

5.0 V

53

(Shield)

—

Antenna amp. shield

—

—

—

—

56

(B)

Ground Satellite antenna signal

Input

ON

AV control unit ON, SXM
selected.

5.0 V

57

(Shield)

—

Satellite antenna shield

—

—

—

—

58

(B)

Ground GPS antenna signal

Input

ON

AV control unit ON, NAV se-
lected.

5.0 V

59

(Shield)

—

GPS antenna shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

CONSULT Display

Reference Page

U1000: CAN COMM CIRCUIT

AV-291, "AV CONTROL UNIT : DTC Logic"

U1010: CONTROL UNIT (CAN)

AV-292, "AV CONTROL UNIT : DTC Logic"

U1217: BLUETOOTH MODULE

AV-309, "DTC Logic"

U1229: iPod CERTIFICATION

AV-310, "DTC Logic"

U122F: Digital broadcasting connection error

AV-311, "DTC Logic"

U1244: GPS ANTENNA CONN

AV-313, "DTC Logic"

U1258: SXM ANTENNA CONN

AV-314, "DTC Logic"

U1263: USB OVERCURRENT

AV-315, "DTC Logic"

U12AA: Configuration Error

AV-317, "DTC Logic"

U12AB: FM Antenna error

AV-318, "DTC Logic"

U12AC: Display Temperature too High

AV-319, "DTC Logic"

U12AD: ECU Temperature too High

AV-320, "DTC Logic"

U12AE: Internal Amplifier temperature Warning

AV-321, "DTC Logic"

U12AF: CD Mechanism Temperature Warning

AV-322, "DTC Logic"

U12B0: Supply Voltage Goes below 9V > 20s

AV-323, "DTC Logic"

U12B1: Supply Voltage Goes High > 16V for 20s

AV-324, "DTC Logic"

U1300: AV COMM CIRCUIT

AV-325, "DTC Logic"

U1310: CONTROL UNIT(AV)

AV-329, "DTC Logic"

AV

BOSE SPEAKER AMP

AV-243

< ECU DIAGNOSIS INFORMATION >

[NAVIGATION WITH BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

BOSE SPEAKER AMP

Reference Value

INFOID:0000000011276932

TERMINAL LAYOUT

PHYSICAL VALUES

ALNIA1599ZZ

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

Ignition

switch

Operation

1

 (L)

10

(R)

Rear door speaker signal
LH

Output

ON

Sound output

2

 (LG)

3

 (V)

Rear door speaker signal
RH

Output

ON

Sound output

4

 (BR)

5

 (P)

Front door speaker signal
LH

Output

ON

Sound output

6

 (W)

7

 (GR)

Front tweeter signal LH

Output

ON

Sound output

SKIA0177E

SKIA0177E

SKIA0177E

SKIA0177E
