Nissan Maxima. Manual - part 787

INT-18

< REMOVAL AND INSTALLATION >

FRONT DOOR FINISHER

REMOVAL AND INSTALLATION

FRONT DOOR FINISHER

Exploded View

INFOID:0000000009465881

Removal and Installation

INFOID:0000000009465882

REMOVAL

1. Remove the step lamp. Refer to

INL-84, "Removal and Installation"

.

1.

Mirror cover

2.

Front door finisher

3.

Step lamp

4.

Arm rest finisher

5.

Main power window and door lock/
unlock switch finisher

6.

Front door grip cover

7.

Seat memory switch (if equipped)

8.

Inside release handle escutcheon

9.

Inside release handle

A.

Flat head screws

B.

Screws

Front

Metal clip

Pawl

Clip

AWJIA0782ZZ

FRONT DOOR FINISHER

INT-19

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

INT

N

O

P

2. Release the pawls at the rear edge and remove the inside release handle escutcheon, then remove the

screw.

3. Remove the front door grip cover (1) by using a suitable tool to

release the pawls.

CAUTION:

• Use suitable tool to release at the point shown or damage

may occur to the pawls.

• Lift upward on front door grip cover to release pawls and

remove.

• Wrap the tip of a suitable tool with a cloth when removing

metal clips from finisher.

4. Remove the front door grip clip (A).

5. Remove the front door grip screw (A).

6. Remove the power window and door lock/unlock switch and finisher as an assembly. Refer to

PWC-107,

"Removal and Installation"

 (MAIN) or

PWC-108, "Removal and Installation"

 (RH).

ALJIA0359ZZ

ALJIA0360ZZ

ALJIA0367ZZ

INT-20

< REMOVAL AND INSTALLATION >

FRONT DOOR FINISHER

7. Remove the front door finisher screw (A) under power window

and door lock/unlock switch finisher.

8. Release the front door finisher clips using a suitable tool (A).

: Clip

9. Disconnect the harness connector from the seat memory switch (if equipped).
10. Disconnect inside handle and lock knob cables from front door finisher.
11. Disconnect the harness connector from the power window and door lock/unlock switch lamp.
12. Remove the front door finisher.

INSTALLATION

Installation is in the reverse order of removal.

• If installing a new front door finisher, transfer all the necessary parts to the new front door finisher.

ALJIA0366ZZ

ALJIA0729ZZ

REAR DOOR FINISHER

INT-21

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

INT

N

O

P

REAR DOOR FINISHER

Exploded View

INFOID:0000000009465883

Removal and Installation

INFOID:0000000009465884

CAUTION:

Wrap the tip of a suitable tool with a cloth when removing metal clips from finishers.

REMOVAL

1. Remove the step lamp. Refer to

INL-84, "Removal and Installation"

.

2. Release the pawls at the rear edge and remove the inside release handle escutcheon, then remove the

screw.

3. Remove the rear door armrest.
a. Lift up to release the rear door armrest pawls.
b. Disconnect the harness connector from the rear power window switch.

1.

Rear door finisher

2.

Step lamp

3.

Armrest finisher

4.

Rear power window switch finisher

5.

Inside release handle escutcheon

6.

Inside release handle

A.

Flat head screws

B.

Screw

Clip

Pawl

Front

AWJIA0783ZZ
