Nissan Maxima. Manual - part 674





2014

QUICK REFERENCE CHART: MAXIMA

Rear Wheel Alignment (Unladen*

1

)

INFOID:0000000010197443

*1: Fuel, engine coolant, and lubricants are full. Spare tire, jack, hand tools, and mats are in designated positions.
*2: 18" tire.
*3: 19" tire.

Wheelarch Height (Unladen*

1

)

INFOID:0000000010197444

Unit: mm (in)

Market

United

States*2

United

States*3

Canada*2

Canada*3

Mexico

Camber
Degree minute
(Decimal degree)

Minimum

−0° 55′

(

−0.92°)

-1

° 02′

(-1.03

°)

−0° 52′

(

−0.87°)

−1° 02′

(

−1.03°)

−0° 10′

(

−0.17°)

Nominal

−0° 25′

(

−0.42°)

-0

° 32′

(-0.53

°)

−0° 22′

(

−0.37°)

−0° 32′

(

−0.53°)

0

° 20′

(0.33

°)

Maximum

0

° 05′

(0.08

°)

-0

° 02′

(-0.03

°)

0

° 08′

(0.13

°)

-0

° 02′

(-0.03

°)

0

° 50′

(0.83

°)

Total toe-in

Distance (A - B)

Minimum

Out 1.4 mm

(Out 0.05 in)

Out 1.1 mm

(Out 0.04 in)

Out 1.4 mm

(Out 0.05 in)

Out 1.1 mm

(Out 0.04 in)

Out 1.4 mm

(Out 0.05 in)

Nominal

In 1.6 mm

(In 0.06 in)

In 1.9 mm

(In 0.07 in)

In 1.6 mm

(In 0.06 in)

In 1.9 mm

(In 0.07 in)

In 1.6 mm

(In 0.06 in)

Maximum

In 4.6 mm

(In 0.18 In)

In 4.9 mm

(In 0.19 in)

In 4.6 mm

(In 0.18 In)

In 4.9 mm

(In 0.19 in)

In 4.6 mm

(In 0.18 In)

Angle (LH and RH)
Degree minute
(Decimal degree)

Minimum

Out 0

° 3′ 36″

(Out 0.06

°)

Out 0

° 2′ 24″

(Out 0.04

°)

Out 0

° 3′ 36″

(Out 0.06

°)

Out 0

° 2′ 24″

(Out 0.04

°)

Out 0

° 3′ 36″

(Out 0.06

°)

Nominal

In 0

° 8′ 24″

(In 0.14

°)

In 0

° 9′ 36″

(In 0.16

°)

In 0

° 8′ 24″

(In 0.14

°)

In 0

° 9′ 36″

(In 0.16

°)

In 0

° 8′ 24″

(In 0.14

°)

Maximum

In 0

° 20′ 24″

(In 0.34

°)

In 0

° 21′ 36″

(In 0.36

°)

In 0

° 20′ 24″

(In 0.34

°)

In 0

° 21′ 36″

(In 0.36

°)

In 0

° 20′ 24″

(In 0.34

°)

SFA234AC

Market

United States

Canada

Mexico

LEIA0085E

QUICK REFERENCE CHART: MAXIMA

2014

*1: Fuel, engine coolant, and lubricants are full. Spare tire, jack, hand tools, and mats are in designated positions.
*2: Without top load sunroof
*3: With top load sunroof

Brake Specifications

INFOID:0000000010197441

Unit: mm (in)

Brake Pedal

INFOID:0000000010197442

Unit: mm (in)

Tire size

P245/

45R18

*2

P245/

45R18

*3

P245/

40R19

*2

P245/

45R18

*2

P245/

45R18

*3

P245/

40R19

*2

P245/

45R18

*2

P245/

40R19

*2

Front (Hf)

719 (28.31)

719 (28.31)

723 (28.46)

720 (28.35)

719 (28.31)

723 (28.46)

729 (28.70)

732 (28.82)

Rear (Hr)

728 (28.66)

727 (28.62)

730 (28.74)

728 (28.66)

727 (28.62)

730 (28.74)

747 (29.41)

750 (29.53)

Brake model

Kiriu

Front brake

Cylinder bore diameter

57.15 (2.250)

Pad length

× width × thickness

123.6

× 47.5 × 11 (4.866 × 1.870 × 0.433)

Rotor outer diameter

× thickness

320

× 28 (12.598 × 1.102)

Rear brake

Brake model

Kiriu

Cylinder bore diameter

34.93 (1.375)

Pad length

× width × thickness

83.0

× 33.0 × 8.5 (3.268 × 1.299 × 0.335)

Rotor outer diameter

× thickness

308

× 16 (12.126 × 0.630)

Master cylinder

Cylinder bore diameter

23.81 (0.937)

Control valve

Valve model

Electric brake force distribution

Brake booster

Booster model

Bosch

Brake pedal free height (H)

190.7 - 202.7 (7.51 - 7.98)

Brake pedal full stroke (S)

130.0 (5.12)

Clearance between brake pedal bracket (C

1

) and threaded end of stop lamp switch and

ASCD cancel switch (C

2

)

0.74 - 1.96 (0.0291 - 0.0772)

AWFIA0557ZZ

2014

QUICK REFERENCE CHART: MAXIMA

Front Disc Brake

INFOID:0000000010197439

Unit: mm (in)

Rear Disc Brake

INFOID:0000000010197440

Unit: mm (in)

FOR USA AND CANADA : Fluids and Lubricants

INFOID:0000000010197433

Brake model

Kiriu

Brake pad

Standard thickness (new)

11.0 (0.433)

Minimum thickness

2.0 (0.079)

Disc rotor

Standard thickness (new)

28.0 (1.102)

Minimum thickness

26.0 (1.024)

Thickness variation (measured at 8 positions)

0.015 (0.0006)

Maximum runout (with it attached to the vehicle)

0.035 (0.0014)

Brake model

Kiriu

Brake pad

Standard thickness (new)

8.5 (0.335)

Minimum thickness

1.0 (0.039)

Disc rotor

Standard thickness (new)

16.0 (0.630)

Minimum thickness

14.0 (0.551)

Thickness variation (measured at 8 positions)

0.015 (0.0006)

Maximum runout (with it attached to the vehicle)

0.05 (0.002)

Description

Capacity (Approximate)

Metric

US measure

Imp measure

Fuel

75.6

20 gal

16-5/8 gal

Engine oil
Drain and refill

With oil filter change

4.8

5-1/8 qt

4-1/4 qt

Without oil filter
change

4.5

4-3/4 qt

4 qt

Dry engine (Overhaul)

5.3

5-5/8 qt

4-5/8 qt

Cooling system
(with reservoir at MAX level)

9.0

9-1/2 qt

7-7/8 qt

CVT fluid

10.2

10-3/4 qt

  9 qt

Power steering fluid (PSF)

1.0

1-1/8 qt

7/8 qt

Brake fluid

Multi-purpose grease

Windshield washer fluid

4.5

4-3/4 qt

4 qt

Air conditioning system refrigerant

0.55

± 0.025 kg

1.21

± 0.055 lb

1.21

± 0.055 lb

Air conditioning system oil

150 m

5.03 fl oz

5.03 fl oz

QUICK REFERENCE CHART: MAXIMA

2014

FOR MEXICO : Fluids and Lubricants

INFOID:0000000010197436

Description

Capacity (Approximate)

Metric

US measure

Imp measure

Fuel

75.6

20 gal

16-5/8 gal

Engine oil
Drain and refill

With oil filter change

4.8

5-1/8 qt

4-1/4 qt

Without oil filter change

4.5

4-3/4 qt

4 qt

Dry engine (engine overhaul)

5.3

5-5/8 qt

4 5/8 qt

Cooling system (with reservoir at MAX level)

9.0

9-1/2 qt

7-7/8 qt

CVT fluid

10.2

10-3/4 qt

9 qt

Power steering fluid

1.0

1-1/8 qt

7/8 qt

Brake fluid

Multi-purpose grease

Air conditioning system refrigerant

0.55

± 0.025 kg

1.21

± 0.055 lb

1.21

± 0.055 lb

Air conditioning system oil

150 m

5.03 fl oz

5.03 fl oz

Windshield washer fluid

4.5

4-3/4 qt

4 qt
