HOMELINK UNIVERSAL TRANSCEIVER DLK-123 < DTC/CIRCUIT DIAGNOSIS > C D E F G H I J L M A B DLK N O P Is the inspection result normal? YES >> GO TO 2 NO >> Check the following. • 10A fuse [No. 6 located in the fuse block (J/B)] • Harness for open or short between fuse and auto anti-dazzling inside mirror (homelink universal transceiver). 2. CHECK GROUND CIRCUIT Check continuity between auto anti-dazzling inside mirror (homelink universal transceiver) harness connector and ground. Is the inspection result normal? YES >> Replace auto anti-dazzling inside mirror (homelink uni- versal transceiver). Refer to NO >> Repair or replace harness. Auto anti-dazzling inside mirror (Homelink universal transceiver) connector Terminal Ground Continuity R4 8 Yes ALKIA0427ZZ |
