AV-276

< ECU DIAGNOSIS INFORMATION >

[COLOR DISPLAY - W/O BOSE]

DISPLAY UNIT

19

(G)

Ground RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(W)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

Shield

—

—

—

—

22

(BR)

Ground

Communication signal
(DISP

→CONT)

Output

Ignition

switch

ON

When adjusting display
brightness

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3603E

SKIB3598E

PKIB5039J

AV

SUBWOOFER AMP

AV-277

< ECU DIAGNOSIS INFORMATION >

[COLOR DISPLAY - W/O BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

SUBWOOFER AMP

Reference Value

INFOID:0000000010075687

TERMINAL LAYOUT

PHYSICAL VALUES

ALNIA1163ZZ

Terminal

(Wire color)

Item

Signal
 input/
output

Condition

Voltage

(approx.)

+

–

Ignition

switch

Operation

2

(LG)

1

 (O)

Audio signal LH

Input

ON

Receive audio signal.

4

(L)

3

 (P)

Audio signal RH

Input

ON

Receive audio signal.

6

 (L)

5

 (P)

Subwoofer audio signal
LH

Output

ON

Receive audio signal.

7

(B)

Ground

Ground

Input

ON

—

—

9

(G)

Ground

ACC power supply

Input

ACC

—

Battery voltage

10

(R)

8

 (BR)

Subwoofer audio signal
RH

Output

ON

Receive audio signal.

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-278

< ECU DIAGNOSIS INFORMATION >

[COLOR DISPLAY - W/O BOSE]

SATELLITE RADIO TUNER

SATELLITE RADIO TUNER

Reference Value

INFOID:0000000010064919

PHYSICAL VALUES

ALNIA1166ZZ

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

22

(W)

21

(BR)

Satellite radio sound signal
LH

Output

Ignition

switch

ON

When satellite radio
mode is selected

24

(B)

23

(Y)

Satellite radio sound signal
RH

Output

Ignition

switch

ON

When satellite radio
mode is selected

28

(R)

Ground

Request signal
(SAT

→CONT)

Output

Ignition

switch

ON

When satellite radio
mode is selected

29

(V)

Ground

Communication signal
(SAT

→CONT)

Output

Ignition

switch

ON

When satellite radio
mode is selected

SKIB3609E

SKIB3609E

SKIA9299J

SKIA9300J

AV

SATELLITE RADIO TUNER

AV-279

< ECU DIAGNOSIS INFORMATION >

[COLOR DISPLAY - W/O BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

30

(L)

Ground

Communication signal
(CONT

→SAT)

Input

Ignition

switch

ON

When satellite radio
mode is selected

32

(P)

Ground Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

35

(B)

—

Shield

—

—

—

—

36

(GR)

Ground ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIA9301J
