A fully charged Altima Hybrid 12-volt battery should read between 12.6 to 12.8 volts.

8. Disconnect the negative (-) charging cable.

9. Disconnect the positive (+) charging cable.

10. Reconnect the negative (-) battery cable to the 12-volt battery.

11. Reinstall the trunk side finisher (RH).

Work Flow

INFOID:0000000004495154

TROUBLE DIAGNOSIS - ALTIMA HYBRID 12-VOLT BATTERY

For battery testing refer to Technical Service Bulletin.

Special Repair Requirement

INFOID:0000000004219219

Required Procedure After Battery Disconnection

System

Item

Reference

Brake Control

Steering Angle Sensor Neutral Position

Refer to

BRC-9

.

Glass, Window & Mirrors

Power Window System Initialization

LH only anti-pinch, refer to

PWC-8

.

LH & RH front anti-pinch, refer to

PWC-

102

.

Roof

Sunroof Memory Reset/Initialization

Refer to

RF-6

.

Automatic Temperature Control

Temperature Setting Trimmer

Refer to

HAC-5

.

Foot Position Setting Trimmer

Refer to

HAC-5

.

Inlet Port Memory Function

Refer to

HAC-5

.

Audio-Visual System

Audio (Radio Preset)

Refer to Owner's Manual.

NAVI

Refer to Owner's Manual.

Rear View Monitor Guiding Line Adjustment

Refer to

AV-148

.

PG-4

< COMPONENT DIAGNOSIS >

POWER SUPPLY ROUTING CIRCUIT

COMPONENT DIAGNOSIS

POWER SUPPLY ROUTING CIRCUIT

Wiring Diagram —Battery Power Supply —
