TM-22

< PRECAUTION >

[HYBRID TRANSAXLE: RE0F01H]

PRECAUTIONS

Service Notice or Precaution

INFOID:0000000004212379

CVT FLUID COOLER SERVICE

If CVT fluid contains friction material (clutches, brakes, etc.), or if a CVT is replaced, inspect and clean the

CVT fluid cooler mounted in the radiator or replace the radiator. Flush cooler lines using cleaning solvent and

compressed air after repair. For CVT fluid cooler cleaning procedure, refer to

HBC-636, "Inspection"

. For radi-

ator replacement, refer to

CO-14, "Removal and Installation"

.

OBD-II SELF-DIAGNOSIS

• CVT self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through

the blinking pattern of the malfunction indicator lamp (MIL). Refer to the table on

HBC-81, "CONSULT-III

Function"

 for the indicator used to display each self-diagnostic result.

• The self-diagnostic results indicated by the MIL are automatically stored in both the ECM and TCM memo-

ries.

Always perform the procedure on

HBC-80, "Diagnosis Description"

 to complete the repair and avoid

unnecessary blinking of the MIL.

For details of OBD-II, refer to

HBC-80, "Diagnosis Description"

.

• Certain systems and components, especially those related to OBD, may use the new style slide-lock-

ing type harness connector. For description and how to disconnect, refer to

PG-59, "Description"

.

PREPARATION

TM-23

< PREPARATION >

[HYBRID TRANSAXLE: RE0F01H]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

PREPARATION

PREPARATION

Commercial Service Tools

INFOID:0000000004212380

Tool name
(Kent-Moore No.)

Description

Insulation groves

Guaranteed insulation performance for 1000V/300A

JMCIA0149ZZ

TM-24

< ON-VEHICLE MAINTENANCE >

[HYBRID TRANSAXLE: RE0F01H]

FLUID

ON-VEHICLE MAINTENANCE

FLUID

Inspection

INFOID:0000000004212381

1. Remove the filler plug and check the fluid level as shown.

2. Install the filler plug with a new gasket and tighten to the speci-

fied torque.

CAUTION:

Do not reuse gasket.

3. Inspect transaxle for fluid leaks.

Replacement

INFOID:0000000004212382

1. Remove the filler plug and gasket (1) from the transaxle.
2. Remove the drain plug and gasket (2) and drain the fluid from

the transaxle.

3. Install the drain plug with a new gasket to the transaxle.

CAUTION:

Do not reuse gasket.

4. Fill the transaxle with specified fluid to the fluid level "A" as

shown.

CAUTION:

• Use only the specified Genuine Nissan fluid, using fluid

other than the Genuine Nissan specified fluid will deterio-

rate in driveability and durability, and may damage the

transaxle, which is not covered by the warranty.

• Do not spill fluid on heat generating parts such as exhaust manifold.

• Do not overfill the transaxle.

• Recheck the fluid level after driving the vehicle to warm up the fluid.

5. Install the filler plug with a new gasket to the transaxle.

CAUTION:

Do not reuse gasket.

Oil level "A":

MAX 5 mm (0.20 in)

Filler plug

: 39.2 N·m (4.0 kg-m, 29 ft-lb)

ALDIA0085ZZ

ALDIA0137ZZ

Fluid grade and capacity: Refer to

MA-10, "Fluids and

Lubricants"

.

Oil level "A":

MAX 5 mm (0.20 in)

Filler plug:

: 39.2 N·m (4.0 kg-m, 29 ft-lb)

ALDIA0085ZZ

LINE PRESSURE TEST

TM-25

< ON-VEHICLE MAINTENANCE >

[HYBRID TRANSAXLE: RE0F01H]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

LINE PRESSURE TEST

Inspection

INFOID:0000000004212383

1. Remove the fluid pump cover plug and install suitable tool (A) as

shown.

2. Measure the fluid pressure.

3. Remove the suitable tool and install the fluid pump cover plug

(A) with a new gasket (1) and tighten to the specified torque.

CAUTION:

Do not reuse the gasket.

Fluid pressure : 9.8 kPa (0.1 kg/cm

2

, 1.4 psi) or more

ALDIA0086ZZ

Fluid pump cover plug

: 8.0 N·m (0.82 kg-m, 71 in-lb)

ALDIA0088GB
