AV-280

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITH NAVIGATION]

CD CHANGER

CD CHANGER

Removal and Installation

INFOID:0000000004219616

REMOVAL

1. Remove Cluster lid D lower finisher. Refer to

IP-12, "Removal and Installation"

.

2. Put selector lever in the drive (D) position.
3. Using a suitable tool remove the CD changer finisher (1), then

disconnect the power socket, AUX jack connectors and remove

the CD changer finisher (1).

4. Remove the CD changer screws (A), pull out the unit, then dis-

connect the CD changer connector and remove the CD changer

(1).

5. Remove the CD changer bracket screws (A).

• CD changer brackets (1)

• CD changer (2)

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0047ZZ

ALNIA0048ZZ

ALNIA0049ZZ

AV

TWEETER

AV-281

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

TWEETER

Removal and Installation

INFOID:0000000004487159

REMOVAL

1. Remove the front pillar finisher. Refer to

INT-23, "Removal and Installation"

.

2. Remove tweeter speaker grille. Refer to

IP-12, "Removal and Installation"

.

3. Remove the tweeter speaker screws (A), disconnect the tweeter

speaker connector and remove the tweeter speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0180GB

AV-282

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITH NAVIGATION]

CENTER SPEAKER

CENTER SPEAKER

Removal and Installation

INFOID:0000000004487160

REMOVAL

1. Remove the center speaker grille. Refer to

IP-12, "Removal and Installation"

.

2. Remove the center speaker screws (A), then pull out the center

speaker (1), disconnect the connector and remove the center

speaker (1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0181GB

AV

FRONT DOOR SPEAKER

AV-283

< ON-VEHICLE REPAIR >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

FRONT DOOR SPEAKER

Removal and Installation

INFOID:0000000004487161

REMOVAL

1. Remove the front door finisher. Refer to

INT-14, "Removal and Installation"

.

2. Remove the front door speaker screws (A), then disconnect the

front door speaker connector and remove the front door speaker

(1).

INSTALLATION

Installation is in the reverse order of removal.

ALNIA0040ZZ
