AV-260

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

BOSE SPEAKER AMP

53

(W/B)

48

(G/B)

Sound signal woofer LH

Output

Ignition

switch ON

54

(L)

49

 (B/W)

Sound signal rear door RH

Output

Ignition

switch ON

58

 (W)

59

(B)

Sound signal front door speaker LH

Output

Ignition

switch ON

60

(B/G)

Ground

Amp. ON signal

Input

Ignition

switch ACC

Battery voltage

64

(BR)

63

 (Y)

Sound signal rear LH

Input

Ignition

switch ON

66

(LG)

65

(V)

Sound signal rear RH

Input

Ignition

switch ON

68

(R/G)

55

(BR/B)

Sound signal rear door LH

Output

Ignition

switch ON

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV

BOSE SPEAKER AMP

AV-261

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

69

(B/P)

70

(O/B)

Sound signal center speaker

Output

Ignition

switch ON

71

(G/W)

72

(BR)

Sound signal front door speaker RH

Output

Ignition

switch ON

73

(W/L)

74

(GR/V)

Sound signal front RH

Input

Ignition

switch ON

75

(W/R)

76

(B/R)

Sound signal front LH

Input

Ignition

switch ON

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/Output

SKIB3609E

SKIB3609E

SKIB3609E

SKIB3609E

AV-262

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

REAR VIEW CAMERA CONTROL UNIT

REAR VIEW CAMERA CONTROL UNIT

Reference Value

INFOID:0000000004219606

TERMINAL LAYOUT

PHYSICAL VALUES

WKIA5224E

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

Signal name

Input/

Output

Ignition

switch

Operation

1

 (Y)

Ground

Battery power

Input

OFF

—

Battery voltage

2

(V)

Ground

ACC power

Input

ACC

—

Battery voltage

3

 (B)

Ground

Ground

—

ON

—

0V

4

(P/B)

Ground

Reverse signal input

Input

ON

CVT selector lever R
position

Battery voltage

CVT selector lever in
other than R position

0V

5

(V/G)

Ground

AV Control

Output

ON

—

0V

6

 (O)

Ground

DDL

Output

—

—

—

8

(GR)

Ground

Camera power output

Output

ON

CVT selector lever R
position

6V

9

(L)

Ground

Camera image input (–)

Input

ON

—

0V

10

(P)

Ground

Camera image input (+)

Input

ON

CVT selector lever R
position

SKIA4894E

AV

REAR VIEW CAMERA CONTROL UNIT

AV-263

< ECU DIAGNOSIS >

[BOSE AUDIO WITH NAVIGATION]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

11

(R)

Ground

Composite image output (-)

Output

ON

CVT selector lever R
position

12

(W)

Ground

Composite image output (+)

Output

ON

CVT selector lever R
position

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

Signal name

Input/

Output

Ignition

switch

Operation

SKIA4896E

SKIA4896E
