DLN-242 < UNIT DISASSEMBLY AND ASSEMBLY > [C200] REAR FINAL DRIVE 10. Press the new side bearing inner races to the differential case using Tools. CAUTION: Do not reuse side bearing inner race. 11. Install the differential case assembly with the side bearing outer races into gear carrier. 12. Measure the side bearing preload torque. If necessary, select the appropriate side bearing adjusting washers. Refer to 225, "Disassembly and Assembly" . 13. Insert the selected left and right side bearing adjusting washers in place between the side bearings and gear carrier using Tool. 14. Install the side bearing caps with the matching marks aligned and tighten the side bearing cap bolts to the specified torque. DLN-225, "Disassembly and Assembly" 15. Check and adjust the drive gear runout, tooth contact, drive gear to drive pinion backlash, and total pre- load torque. Refer to " DLN-225, "Disassembly and Assembly" Recheck above items. Tool number (A): ST33230000 (J-25805-01) SPD353 SPD527 Tool number : KV38100600 (J-25267) SPD709 SPD889 |
