L TERMINAL CIRCUIT (OPEN)

CHG-15

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

Is the inspection result normal?

YES

>> GO TO 5.

NO

>> Repair or replace the harness or connectors.

5.

CHECK POWER SUPPLY CIRCUIT

1. Connect the battery cable to the negative terminal.

2. Check voltage between combination meter harness connector and ground.

Is the inspection result normal?

YES

>> Replace the combination meter. Refer to

MWI-90, "Removal and Installation"

 .

NO

>> Repair or replace the harness or connectors.

(+)

(-)

Condition

Voltage

(Approx.)

Combination meter

Connector

Terminal

M24

16

Ground

When the ignition

switch is in ON position

Battery voltage

CHG-16

< DTC/CIRCUIT DIAGNOSIS >

L TERMINAL CIRCUIT (SHORT)

L TERMINAL CIRCUIT (SHORT)

Description

INFOID:0000000009482321

The terminal “L” circuit controls the charge warning lamp. The charge warning lamp turns ON when the igni-

tion switch is set to ON or START. When the generator is providing sufficient voltage with the engine running,

the charge warning lamp turns off. If the charge warning lamp illuminates with the engine running, a malfunc-

tion is indicated.

Diagnosis Procedure

INFOID:0000000009482322

Regarding Wiring Diagram information, refer to

CHG-18, "Wiring Diagram"

.

1.

CHECK “L” TERMINAL CIRCUIT (SHORT)

1. Turn ignition switch OFF.

2. Disconnect generator connector.

3. Turn ignition switch ON.
Does charge warning lamp illuminate?

YES

>> GO TO 2.

NO

>> Refer to

CHG-2, "Work Flow (With EXP-800 NI or GR8-1200 NI)"

 or

CHG-5, "Work Flow (Without

EXP-800 NI or GR8-1200 NI)"

.

2.

CHECK HARNESS CONTINUITY (SHORT CIRCUIT)

1. Turn ignition switch OFF.

2. Disconnect the battery cable from the negative terminal.

3. Disconnect combination meter connector.

4. Check continuity between the combination meter harness connector and ground.

Is the inspection result normal?

YES

>> Replace the combination meter. Refer to

MWI-90, "Removal and Installation"

.

NO

>> Repair or replace the harness or connectors.

Combination meter

Ground

Continuity

Connector

Terminal

M24

2

No

CHG

S TERMINAL CIRCUIT

CHG-17

< DTC/CIRCUIT DIAGNOSIS >

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

S TERMINAL CIRCUIT

Description

INFOID:0000000009482323

The output voltage of the generator is controlled by the IC regulator at terminal “S” detecting the input voltage

from battery.

The “S” terminal circuit detects the battery voltage to adjust the generator output voltage with the IC voltage

regulator.

Diagnosis Procedure

INFOID:0000000009482324

Regarding Wiring Diagram information. Refer to

CHG-18, "Wiring Diagram"

.

1.

CHECK “S” TERMINAL CONNECTION

1. Turn ignition switch OFF.

2. Check if “S” terminal is clean and tight.
Is the inspection result normal?

YES

>> GO TO 2.

NO

>> Repair “S” terminal connection. Confirm repair by performing complete Charging system test

using EXP-800 NI or GR8-1200 NI (if available). Refer to the applicable Instruction Manual for

proper testing procedures.

2.

CHECK “S” TERMINAL CIRCUIT

Check voltage between generator harness connector and ground.

Is the inspection result normal?

YES

>> Refer to

CHG-2, "Work Flow (With EXP-800 NI or GR8-1200 NI)"

 or

CHG-5, "Work Flow (Without

EXP-800 NI or GR8-1200 NI)"

.

NO

>> Check harness for open between generator and fuse.

(+)

(-)

Voltage

(Approx.)

Generator

Connector Terminal

E205

3

Ground

Battery voltage

CHG-18

< WIRING DIAGRAM >

CHARGING SYSTEM

WIRING DIAGRAM

CHARGING SYSTEM

Wiring Diagram

INFOID:0000000009482325

ABMWA2333GB
