WT-28 < ECU DIAGNOSIS INFORMATION > BCM (BODY CONTROL MODULE) Terminal Wire color Item Signal input/ output Measuring condition Reference value or waveform (Approx.) Ignition switch Operation or condition 1 BR Ignition keyhole illumi- Output OFF Door is locked (SW OFF) Battery voltage Door is unlocked (SW ON) 0V 2 P Combination switch Input ON Lighting, turn, wiper OFF 3 SB Combination switch Input ON Lighting, turn, wiper OFF 4 V Combination switch Input ON Lighting, turn, wiper OFF 5 L Combination switch Input ON Lighting, turn, wiper OFF 6 R Combination switch 7 GR Front door lock as- Input OFF ON (open, 2nd turn) Momentary 1.5V OFF (closed) 0V 8 SB Front door lock as- Input On (open) Momentary 1.5V OFF (closed) 0V 9 LG Brake sw Input OFF OFF (brake pedal is not de- 0V ON (brake pedal is de- Battery voltage 11 G/B Ignition switch (ACC Input ACC or ON Ignition switch ACC or ON Battery voltage 12 LG Front door switch RH Input OFF ON (open) 0V Rear door switch up- OFF (closed) Battery voltage Rear door switch low- SKIA5291E SKIA5292E SKIA5291E SKIA5292E |
