Nissan Frontier. Manual - part 15

AV-52

< REMOVAL AND INSTALLATION >

[BASE AUDIO (EXCEPT MEXICO)]

REAR DOOR SPEAKER

REAR DOOR SPEAKER

Removal and Installation

INFOID:0000000009482096

REMOVAL

1. Remove the rear door finisher. Refer to

INT-15, "Removal and Installation"

.

2. Remove the rear door speaker screws (A).
3. Disconnect the harness connector (B) from the rear door

speaker (1) and remove.

NOTE:

King cab shown, crew cab similar.

INSTALLATION

Installation is in the reverse order of removal.

ALNIA1071ZZ

AV

STEERING SWITCH

AV-53

< REMOVAL AND INSTALLATION >

[BASE AUDIO (EXCEPT MEXICO)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

STEERING SWITCH

Removal and Installation

INFOID:0000000010239655

Removal and Installation

REMOVAL

1. Remove the driver air bag module. Refer to

SR-11, "Removal and Installation"

.

2. Remove the steering wheel audio control switch assembly screws.
3. Disconnect the harness connectors from the steering wheel audio control switches.
4. Remove the steering wheel audio control switches by pulling on

steering wheel audio control switches to release the pawls.

: Pawl

CAUTION:

Do not tilt steering wheel audio control switches during

removal or damage may occur to the pawls.

INSTALLATION

Installation is in the reverse order of removal.

1. Steering wheel

2.

Steering wheel audio control switches

ALNIA0357ZZ

ALNIA1214ZZ

AV-54

< REMOVAL AND INSTALLATION >

[BASE AUDIO (EXCEPT MEXICO)]

BLUETOOTH CONTROL UNIT

BLUETOOTH CONTROL UNIT

Removal and Installation

INFOID:0000000010239656

REMOVAL

NOTE:

Do not remove the RH front seat from the vehicle.
1. Remove the RH front seat bolts, disconnect the harness connectors from the RH front seat. Refer to

SE-

32, "Removal and Installation"

.

2. Tilt the RH front seat back to access the bluetooth control unit.

1.

Bluetooth control unit front bracket

2.

Bluetooth control unit/antenna

3.

Bluetooth control unit rear bracket

Front

ALNIA1069ZZ

AV

BLUETOOTH CONTROL UNIT

AV-55

< REMOVAL AND INSTALLATION >

[BASE AUDIO (EXCEPT MEXICO)]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

3. Disconnect the harness connector (B) from the Bluetooth control

unit.

4. Remove the Bluetooth control unit screws (A), then remove the

Bluetooth control unit assembly (1).

5. Remove the Bluetooth control unit bracket screws and Bluetooth

control unit front and rear brackets.

INSTALLATION

Installation is in the reverse order of removal.

AWNIA1812ZZ
