Nissan Sentra. Manual - part 903

TM-248

< SYMPTOM DIAGNOSIS >

[CVT: RE0F11A]

CVT CONTROL SYSTEM

Other

Starter operates in “D”, “L”, or
“R” position.

1

1

1

Starter does not operate in
“P” or “N” position.

1

1

1

Engine stall occurs in “D”, “L”,
or “R” position during stop.

1

1

1

1

Engine stall occurs in “P” or
“N” position during stop.

1

1

1

1

Parking lock does not oper-
ate in “P” position.

1

1

Parking lock cannot be can-
celled when the selector le-
ver is shifted from “P” position
to other position.

1

1

Symptom

Check under on board condition (repair

and part replacement)

Replace the transaxle assembly.

En

gi

ne

 s

ys

tem

In

co

rrec

t

adj

ust

me

nt

 of

 CVT f

lui

d l

ev

el



Li

ne

 pre

ss

u

re

 is o

u

t of

 th

e

st

an

da

rd va

lu

e.



Co

ntro

l c

a

ble

Electric system

TC

M

Ov

erd

riv

e c

on

tro

l s

w

itc

h

Prim

ary

 s

p

ee

d se

nso

r (P07

15

)

Se

cond

ary

 s

pe

ed

 s

en

so

r (P27

65

)

Out

put

 sp

ee

d se

ns

or (P0

7

20

)

T

ran

sm

is

si

on

 po

si

tio

n

 swi

tch

 (P0

7

05

, P07

0

6)

Se

cond

ary

 p

res

su

re

se

ns

or (P

08

46,

 P0

84

7, P

08

48

)

Pri

m

a

ry

pre

ss

ure

 s

ole

no

id

 va

lv

e

(P09

65

, P0

96

6,

P09

67

)

Li

ne

 pre

ss

u

re

 s

o

le

no

id

 v

a

lve

 (P07

46

, P0

96

2,

 P09

6

3)

L

oc

k-u

p so

le

noi

d va

lve

(P0

74

0,

 P0

743

, P

07

44)

Hi

gh

 cl

utc

h

&rev

ers

e

bra

ke

 s

ole

no

id

 va

lv

e

(P09

9B,

 P0

99

C,

 P2

85

8,

 P28

5

A)

L

ow

b

rak

e so

le

no

id va

lv

e

(P0

99

8,

 P0

999

, P

28

57,

 P2

85

9)

CVT f

lui

d t

e

m

p

er

at

ur

e se

ns

or (P07

11

, P07

1

2,

 P0

71

3)

EC-126

TM-250

TM-149

TM-150

TM-1

14

TM-236

TM-126

CVT CONTROL SYSTEM

TM-249

< SYMPTOM DIAGNOSIS >

[CVT: RE0F11A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

Symptom diagnosis chart 2-2

Symptom

Replace the transaxle assembly.

Oil pres-

sure con-

trol

Power transmission

V

al

ve bo

dy

, co

nt

rol

 va

lve

Oil pu

mp

To

rqu

e

 co

nv

ert

er

P

ull

ey

, st

ee

l b

elt



L

ow brak

e



Hi

gh

 cl

utc

h

Rev

e

rs

e bra

ke



Be

ari

ngs

Co

un

ter ge

ar

P

lan

et

ary

 ge

ar

Red

uc

tio

n ge

ar

F

ina

l gea

r, dif

fe

ren

tia

l g

ea

r

Pa

rki

ng me

ch

an

is

m

TM

-283

Shock vi-

bration

Noise

Shock at start is large in “D”,
“L”, or “R” position.

1

1

1

(In “D” or

“L”)

1

(In “R”)

2

2

2

2

Shock is large when the auxil-
iary gearbox is shifted from
1GR

→ 2GR.

1

1

1

Shock in lockup is large dur-
ing driving in “D” or “L” posi-
tion.

1

1

Shock is large when the lever
is shifted from “N”

→ “D” and

“N”

→ “R” positions.

1

1

(“N”

→

“D”)

1

(“N”

→

“D”)

Shock is large when the lever
is shifted from “D”

→ “L” posi-

tion.

1

1

1

Vibration occurs in “D”, “L”, or
“R” position during driving.

1

1

1

1

1

(In “D” or

“L”)

1

(In “D” or

“L”)

1

(In “R”)

1

1

1

1

1

Noise  occurs  during  driving.

1

1

1

1

1

1

1

1

Noise occurs in idling.

1

1

1

1

1

1

Other

Starter operates in “D”, “L”, or
“R” position.

Starter does not operate in “P”
or “N” position.

Engine stall occurs in “D”, “L”,
or “R” position during stop.

1

1

Engine stall occurs in “P” or
“N” position during stop.

Parking lock does not operate
in “P” position.

1

Parking lock cannot be can-
celled when the selector lever
is shifted from “P” position to
other position.

1

TM-250

< PERIODIC MAINTENANCE >

[CVT: RE0F11A]

CVT FLUID

PERIODIC MAINTENANCE

CVT FLUID

Inspection

INFOID:0000000009759496

FLUID LEAKAGE

• Check transaxle surrounding area (oil seal and plug etc.) for fluid

leakage.

• If anything is found, repair or replace damaged parts and adjust

CVT fluid level. Refer to

TM-251, "Adjustment"

.

Replacement

INFOID:0000000009759497

CAUTION:

• Use only Genuine NISSAN CVT Fluid NS-3. Using transmission fluid other than Genuine NISSAN

CVT Fluid NS-3 will damage the CVT, which is not covered by the (NISSAN new vehicle limited) war-

ranty.

• Always use shop paper. Never use shop cloth.

• Replace a drain plug gasket with new ones at the final stage of the operation when installing.

• Use caution when looking into the drain hole as there is a risk of dripping fluid entering the eye.

• After replacement, always perform CVT fluid leakage check.
1. Select “Data Monitor” in “TRANSMISSION” using CONSULT.
2. Select “FLUID TEMP” and confirm that the CVT fluid temperature is 40

°C (104°F) or less.

3. Check that the selector lever is in the “P” position, then completely engage the parking brake.
4. Lift up the vehicle.
5. Remove the drain plug and overflow tube and drain the CVT fluid from the oil pan.

TM-266, "Exploded

View"

.

6. Install the charging pipe set (KV311039S0) (A) into the drain

hole.

CAUTION:

Tighten the charging pipe by hand.

7. Install the ATF changer hose (B) to the charging pipe.

CAUTION:

Press the ATF changer hose all the way onto the charging

pipe until it stops.

8. Fill approximately 3 liter (3-1/8 US qt, 2-5/8 lmp qt) of the CVT

fluid.

9. Remove the ATF changer hose and charging pipe, then install

the drain plug.

NOTE:

Perform this work quickly because CVT fluid leaks.

10. Lift down the vehicle.
11. Start the engine.
12. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “L”, and shift it

to the “P” position.

SMA146B

CVT fluid

: Refer to

TM-288, "General Specification"

.

Fluid capacity

: Refer to

TM-288, "General Specification"

.

JSDIA1876ZZ

CVT FLUID

TM-251

< PERIODIC MAINTENANCE >

[CVT: RE0F11A]

C

E

F

G

H

I

J

K

L

M

A

B

TM

N

O

P

NOTE:

Hold the lever at each position for 5 seconds.

13. Check that the CONSULT “Data monitor” in “FLUID TEMP” is 35

°C (95°F) to 45°C (113°F).

14. Stop the engine.
15. Lift up the vehicle.
16. Remove the drain plug, and then drain CVT fluid from oil pan.
17. Repeat steps 6 to 16 (one time).
18. Install the overflow tube. Refer to

TM-266, "Exploded View"

.

CAUTION:

Be sure to tighten to the specified torque. If it is not tightened to the specified torque, the tube may

be damaged.

19. Install the charging pipe set (KV311039S0) (A) into the drain

hole.

CAUTION:

Tighten the charging pipe by hand.

20. Install the ATF changer hose (B) to the charging pipe.

CAUTION:

Press the ATF changer hose all the way onto the charging

pipe until it stops.

21. Fill approximately 3 liter (3-1/8 US qt, 2-5/8 lmp qt) of the CVT

fluid.

22. Remove the ATF changer hose and charging pipe, then install

the drain plug.

NOTE:

Perform this work quickly because CVT fluid leaks.

23. Lift down the vehicle.
24. Start the engine.
25. While depressing the brake pedal, shift the selector lever to the entire position from “P” to “L”, and shift it

to the “P” position.

NOTE:

Hold the lever at each position for 5 seconds.

26. Check that the CONSULT “Data monitor” in “FLUID TEMP” is 35

°C (95°F) to 45°C (113°F).

27. Lift up the vehicle.
28. Remove the drain plug and confirm that the CVT fluid is drained from the overflow tube.

CAUTION:

Perform this work with the vehicle idling.

NOTE:

If the CVT fluid is not drained, refer to “Adjustment” and refill with the CVT fluid.

29. When the flow of CVT fluid slows to a drip, tighten the drain plug to the specified torque.

TM-266,

"Exploded View"

.

CAUTION:

Never reuse drain plug gasket.

30. Lift down the vehicle.
31. Select “Work Support” in “TRANSMISSION” using CONSULT.
32. Select “CONFORM CVTF DETERIORTN”.
33. Touch “Erase”.
34. Stop the engine.

Adjustment

INFOID:0000000009759498

CAUTION:

JSDIA1876ZZ

CVT fluid

: Refer to

TM-288, "General Specification"

.

Fluid capacity

: Refer to

TM-288, "General Specification"

.
