Nissan Sentra. Manual

LU-16

< UNIT DISASSEMBLY AND ASSEMBLY >

[MRA8DE]

OIL PUMP

3. Remove fender protector. Refer to

EXT-28, "FENDER PROTECTOR : Removal and Installation - Front

Fender Protector"

4. Remove timing chain. Refer to

EM-49, "Removal and Installation"

5. Remove oil pump.

• Loosen bolts in reverse order as shown.

INSTALLATION

CAUTION:

Do not reuse O-rings or washers.

Installation is in the reverse order of removal.

Oil Pump

• Tighten bolts in numerical order as shown.

Inspection

INFOID:0000000009756264

INSPECTION AFTER INSTALLATION

1. Check the engine oil level. Refer to

LU-7, "Inspection"

2. Start the engine, and check that there are no leaks of engine oil.
3. Stop the engine and wait for 10 minutes.
4. Check the engine oil level, and adjust the level. Refer to

LU-7, "Inspection"

(1)

: Oil pump

(2)

: Oil pan (upper)

: Engine front

JPBIA4451ZZ

(1)

: Oil pump

(2)

: Oil pan (upper)

: Engine front

JPBIA4451ZZ

SERVICE DATA AND SPECIFICATIONS (SDS)

LU-17

< SERVICE DATA AND SPECIFICATIONS (SDS)

[MRA8DE]

SERVICE DATA AND SPECIFICATIONS (SDS)

Oil Pressure

INFOID:0000000009756265

Unit: kPa (kg/cm

, psi)

*: Engine oil temperature at 80

°C (176°F)

Oil Capacity

INFOID:0000000009756266

Unit: (US qt, lmp qt)

Engine speed

Approximate discharge oil pressure*

Idle speed

71 (0.72, 10.3)

2,000 rpm

200 (2.04, 29.0)

Drain and refill

With oil filter change

4.0 (4-1/4, 3-1/2)

Without oil filter change

3.8 (4, 3-3/8)

Dry engine (Overhaul)

4.8 (5-1/8, 4-1/4)

MA-1

MAINTENANCE

SECTION

CONTENTS

MAINTENANCE

PRECAUTION ...............................................

PRECAUTIONS ...................................................

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................

PREPARATION ............................................

PREPARATION ...................................................

Special Service Tool .................................................

Commercial Service Tool ..........................................

PERIODIC MAINTENANCE ..........................

GENERAL MAINTENANCE ................................

Explanation of General Maintenance ........................

PERIODIC MAINTENANCE ................................

Introduction of Periodic Maintenance ........................

Fluids and Lubricants ..............................................

Engine Oil Recommendation ..................................

Engine Coolant Mixture Ratio .................................

ENGINE MAINTENANCE ...................................

DRIVE BELT ..............................................................

DRIVE BELT : Inspection ........................................

DRIVE BELT : Adjustment ......................................

ENGINE COOLANT ...................................................

ENGINE COOLANT : System Inspection ................

ENGINE COOLANT : Changing Engine Coolant ....

FUEL LINES ..............................................................

FUEL LINES : Inspection ........................................

AIR CLEANER FILTER .............................................

AIR CLEANER FILTER : Component .....................

AIR CLEANER FILTER : Removal and Installation

....

AIR CLEANER FILTER : Inspection ........................

ENGINE OIL ...............................................................

ENGINE OIL : Inspection .........................................

ENGINE OIL : Draining ............................................

ENGINE OIL : Refilling ............................................

OIL FILTER ................................................................

OIL FILTER : Removal and Installation ...................

OIL FILTER : Inspection ..........................................

SPARK PLUG ............................................................

SPARK PLUG : Removal and Installation ...............

SPARK PLUG : Inspection ......................................

EVAP VAPOR LINES ................................................

EVAP VAPOR LINES : Inspection ...........................

CHASSIS AND BODY MAINTENANCE ...........

IN-CABIN MICROFILTER ..........................................

IN-CABIN MICROFILTER : Removal and Installa-
tion ...........................................................................

EXHAUST SYSTEM ...................................................

EXHAUST SYSTEM : Checking Exhaust System ....

M/T OIL ......................................................................

M/T OIL : Inspection ................................................

M/T OIL : Draining ...................................................

M/T OIL : Refilling ....................................................

CVT FLUID .................................................................

CVT FLUID : Inspection ...........................................

CVT FLUID : Replacement ......................................

CVT FLUID : Adjustment .........................................

WHEELS ....................................................................

WHEELS : Inspection ..............................................

WHEELS : Adjustment ............................................

BRAKE FLUID LEVEL AND LEAKS .........................
